Attributes
| Part Number | 3289-000000-000001 |
|---|
Description
# Transmission Oil Cooler Hose
Gates Transmission Oil Cooler Hose is engineered with synthetic rubber tube, and an oil and abrasion resistant black neoprene cover, to provide a safe, heat, ozone, and chemical-resistant connecting line between the oil cooler and transmission. The cooler hose is reinforced with a braided cord for increased strength, supporting a working pressure of 250 psi.
- Easy-to-follow instructions and hose diameter indicator in each package.
- Temperature Range: -40°C to +135°C (-40°F to +275°F).
- Oil and abrasion resistant black neoprene cover.
## Structured Hose Construction
The braided cord construction on Gates® Transmission Oil Cooler Hose is engineered to maintain shape, performance, and structure, even under continuous pressure and in consistently high temperature operating conditions.
## Features and Benefits
- Nitrile tube and CSM cover.
- Synthetic Fiber Reinforcement.
- Meets or exceeds SAE 100R6.
- Offered in 3 ft, 25 ft, and 50 ft lengths.
- Recyclable retail packaging.
## Gates Brings OE to the Aftermarket.
Gates® engineers our industrials aftermarket parts in partnership with the top industrial OEMs around the world, so you can trust premium-grade industrial parts with exceptional fit, function and performance. Our Transmission Oil Cooler Hoses are engineered for leak-resistant service to protect your equipment engines and eliminate transmission fluid loss.
Variations (11)
27056
| Centerline Length (ft) | 3 |
|---|---|
| Hose Inside Diameter (in). | 0.312 |
| Inside Diameter 1 (in) | 0.3125 |
| Inside Diameter 2 (in) | 0.3125 |
| Working Pressure (psi) | 400 |
| Customer Pack | 54 |
| Weight (lbs.) | 0.3 |
27057
| Centerline Length (ft) | 3 |
|---|---|
| Hose Inside Diameter (in). | 0.375 |
| Inside Diameter 1 (in) | 0.375 |
| Inside Diameter 2 (in) | 0.375 |
| Working Pressure (psi) | 400 |
| Customer Pack | 54 |
| Weight (lbs.) | 0.35 |
27058
| Centerline Length (ft) | 25 |
|---|---|
| Hose Inside Diameter (in). | 0.312 |
| Inside Diameter 1 (in) | 0.3125 |
| Inside Diameter 2 (in) | 0.3125 |
| Working Pressure (psi) | 400 |
| Customer Pack | 1 |
| Weight (lbs.) | 2.52 |
27059
| Centerline Length (ft) | 25 |
|---|---|
| Hose Inside Diameter (in). | 0.375 |
| Inside Diameter 1 (in) | 0.375 |
| Inside Diameter 2 (in) | 0.375 |
| Working Pressure (psi) | 400 |
| Customer Pack | 1 |
| Weight (lbs.) | 3.12 |
27060
| Centerline Length (ft) | 50 |
|---|---|
| Hose Inside Diameter (in). | 0.312 |
| Inside Diameter 1 (in) | 0.3125 |
| Inside Diameter 2 (in) | 0.3125 |
| Working Pressure (psi) | 400 |
| Customer Pack | 1 |
| Weight (lbs.) | 5.04 |
27061
| Centerline Length (ft) | 50 |
|---|---|
| Hose Inside Diameter (in). | 0.375 |
| Inside Diameter 1 (in) | 0.375 |
| Inside Diameter 2 (in) | 0.375 |
| Working Pressure (psi) | 400 |
| Customer Pack | 1 |
| Weight (lbs.) | 6.25 |
27065
| Centerline Length (ft) | 3 |
|---|---|
| Hose Inside Diameter (in). | 0.5 |
| Inside Diameter 1 (in) | 0.5 |
| Inside Diameter 2 (in) | 0.5 |
| Working Pressure (psi) | 400 |
| Customer Pack | 24 |
| Weight (lbs.) | 0.53 |
27066
| Centerline Length (ft) | 25 |
|---|---|
| Hose Inside Diameter (in). | 0.5 |
| Inside Diameter 1 (in) | 0.5 |
| Inside Diameter 2 (in) | 0.5 |
| Working Pressure (psi) | 400 |
| Customer Pack | 1 |
| Weight (lbs.) | 4.42 |
27067
| Centerline Length (ft) | 50 |
|---|---|
| Hose Inside Diameter (in). | 0.5 |
| Inside Diameter 1 (in) | 0.5 |
| Inside Diameter 2 (in) | 0.5 |
| Working Pressure (psi) | 400 |
| Customer Pack | 1 |
| Weight (lbs.) | 8.85 |
6TOC TRANS OIL COOLER HOSE
No variation attributes.
33194315
No variation attributes.
Specifications
| Centerline Length (ft) | 3 – 50 |
|---|---|
| Hose Inside Diameter (in). | 0.312 – 0.5 |
| Inside Diameter 1 (in) | 0.3125 – 0.5 |
| Inside Diameter 2 (in) | 0.3125 – 0.5 |
| Working Pressure (psi) | 400 |
| Customer Pack | 1 – 54 |
| Weight (lbs.) | 0.3 – 8.85 |
