# Air Brake Copper Tubing Compression to Male Pipe - 45°
Recommended for air brake systems - compressed air connectors or suspension, steering, engine transmission or on auxiliary components.
- Used with copper tubing in air brake systems.
- Easy to assemble - no flaring tools required.
- Versatile - can be used with nylon tubing by replacing the long nut and sleeve with an insert, rigid sleeve and nut.
- Meets DOT FMVSS 571.106, SAE J246 and SAE J1131 requirements.
- Temperature Range: -65 Deg. F to +250 Deg. F (-53 Deg. C to +121 Deg. C).
Variations (4)
10ABCT-8MP45 / G30102-1008
| End 2 Diameter (mm) | 8 |
|---|---|
| A1 Outside Diameter (in) | 0.625 |
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Angle. | 45 |
| End 1 Diameter (mm) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.3 |
6ABCT-4MP45 / G30102-0604
| End 2 Diameter (mm) | 4 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Angle. | 45 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
6ABCT-6MP45 / G30102-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Angle. | 45 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
8ABCT-6MP45 / G30102-0806
| End 2 Diameter (mm) | 6 |
|---|---|
| A1 Outside Diameter (in) | 0.5 |
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Angle. | 45 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
Specifications
| End 2 Diameter (mm) | 4 – 8 |
|---|---|
| A1 Outside Diameter (in) | 0.375 – 0.625 |
| A1 Outside Diameter (mm) | 9.5 – 15.9 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Angle. | 45 |
| End 1 Diameter (mm) | 6 – 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 – 0.3 |
