Attributes
| Part Number | 7250-000000-000012 |
|---|
Description
# Air Brake Compression Tube Support Insert
Recommended for use in air brake systems - compressed air for suspension, steering, engine transmission or other onboard vehicle applications. For use as a connector on all air brake systems at locations other than between chassis frame and axle or between towed and towing vehicle. Easy to assemble - field serviceable fitting consists of four component parts.
- Meets DOT FMVSS 571.106, SAE J246, SAE J1131, DIN 74324 and German TUV requirements.
- For use with SAE J844 and DIN 74324 nylon tubing.
- Temperature Range: -40 Deg. F to +200 Deg. F (-40 Deg. C to +93 Deg. C).
Variations (10)
10TSI-ABC / G32040-0010
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
10TSI-ABCB / G32040-0010B
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
12TSI-ABC / G32040-0012
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
12TSI-ABCB / G32040-0012B
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.21 |
4TSI-ABC / G32040-0004
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 5 |
| Weight (lbs.) | 0.15 |
4TSI-ABCB / G32040-0004B
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.03 |
6TSI-ABC / G32040-0006
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.002 |
6TSI-ABCB / G32040-0006B
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.05 |
8TSI-ABC / G32040-0008
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
8TSI-ABCB / G32040-0008B
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.09 |
Specifications
| A1 Outside Diameter (in) | 0.25 – 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 – 19.1 |
| Max. Working Pressure | 150 |
| Max. Working Pressure (Bar) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 – 5 |
| Weight (lbs.) | 0.002 – 0.21 |
