Attributes
| Part Number | 4663-000000-000001 |
|---|
Description
# Air Duct Hose
RECOMMENDED FOR: Heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. For standard- and heavy-duty applications.
- Oil-resistant tube.
- CAUTION: Not recommended for conveying liquids.
- For standard–duty applications.
Variations (66)
1-1/2X10 AIR DUCT 15SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 2 |
| Minimum Bend Radius (mm) | 38 |
| Min. Burst Pressure (psi) | 60 |
| Hose Inside Diameter (in). | 1.5 |
| Hose Inside Diameter (mm) | 38.1 |
| Hose Outside Diameter (in) | 1.75 |
| Hose Outside Diameter (mm) | 44.5 |
| Inside Diameter (in) | 1.5 |
| Inside Diameter (mm) | 38.1 |
| Working Pressure (psi) | 15 |
| Length (m) | 3 |
| Outside Diameter (in) | 1.75 |
| Outside Diameter (mm) | 38.1 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.48 |
1-1/4X10 AIR DUCT 20SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 1 |
| Minimum Bend Radius (mm) | 25 |
| Min. Burst Pressure (psi) | 80 |
| Hose Inside Diameter (in). | 1.25 |
| Hose Inside Diameter (mm) | 31.8 |
| Hose Outside Diameter (in) | 1.5 |
| Hose Outside Diameter (mm) | 38.1 |
| Inside Diameter (in) | 1.25 |
| Inside Diameter (mm) | 31.8 |
| Working Pressure (psi) | 20 |
| Length (m) | 3 |
| Outside Diameter (in) | 1.5 |
| Outside Diameter (mm) | 31.8 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.34 |
1-3/4X10 AIR DUCT 15SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 2 |
| Minimum Bend Radius (mm) | 46 |
| Min. Burst Pressure (psi) | 60 |
| Hose Inside Diameter (in). | 1.75 |
| Hose Inside Diameter (mm) | 44.5 |
| Hose Outside Diameter (in) | 2 |
| Hose Outside Diameter (mm) | 50.8 |
| Inside Diameter (in) | 1.75 |
| Inside Diameter (mm) | 44.5 |
| Working Pressure (psi) | 15 |
| Length (m) | 3 |
| Outside Diameter (in) | 2 |
| Outside Diameter (mm) | 44.5 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.54 |
1-3/8X10 AIR DUCT 15SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 2 |
| Minimum Bend Radius (mm) | 38 |
| Min. Burst Pressure (psi) | 60 |
| Hose Inside Diameter (in). | 1.38 |
| Hose Inside Diameter (mm) | 34.9 |
| Hose Outside Diameter (in) | 1.62 |
| Hose Outside Diameter (mm) | 41.1 |
| Inside Diameter (in) | 1.38 |
| Inside Diameter (mm) | 34.9 |
| Working Pressure (psi) | 15 |
| Length (m) | 3 |
| Outside Diameter (in) | 1.62 |
| Outside Diameter (mm) | 34.9 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.44 |
1-5/8X10 AIR DUCT 15SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 2 |
| Minimum Bend Radius (mm) | 46 |
| Min. Burst Pressure (psi) | 60 |
| Hose Inside Diameter (in). | 1.63 |
| Hose Inside Diameter (mm) | 41.3 |
| Hose Outside Diameter (in) | 1.88 |
| Hose Outside Diameter (mm) | 47.8 |
| Inside Diameter (in) | 1.63 |
| Inside Diameter (mm) | 41.3 |
| Working Pressure (psi) | 15 |
| Length (m) | 3 |
| Outside Diameter (in) | 1.88 |
| Outside Diameter (mm) | 41.3 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.51 |
1-7/8X10 AIR DUCT 15SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 2 |
| Minimum Bend Radius (mm) | 46 |
| Min. Burst Pressure (psi) | 60 |
| Hose Inside Diameter (in). | 1.88 |
| Hose Inside Diameter (mm) | 47.6 |
| Hose Outside Diameter (in) | 2.12 |
| Hose Outside Diameter (mm) | 53.8 |
| Inside Diameter (in) | 1.88 |
| Inside Diameter (mm) | 47.6 |
| Working Pressure (psi) | 15 |
| Length (m) | 3 |
| Outside Diameter (in) | 2.12 |
| Outside Diameter (mm) | 47.6 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.58 |
1X10 AIR DUCT 20SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 1 |
| Minimum Bend Radius (mm) | 25 |
| Min. Burst Pressure (psi) | 80 |
| Hose Inside Diameter (in). | 1 |
| Hose Inside Diameter (mm) | 25.4 |
| Hose Outside Diameter (in) | 1.25 |
| Hose Outside Diameter (mm) | 31.8 |
| Inside Diameter (in) | 1 |
| Inside Diameter (mm) | 25.4 |
| Working Pressure (psi) | 20 |
| Length (m) | 3 |
| Outside Diameter (in) | 1.25 |
| Outside Diameter (mm) | 25.4 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.26 |
2 X 10' 4663A VFM
No variation attributes.
2-1/2X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 64 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 2.5 |
| Hose Inside Diameter (mm) | 63.5 |
| Hose Outside Diameter (in) | 2.75 |
| Hose Outside Diameter (mm) | 69.9 |
| Inside Diameter (in) | 2.5 |
| Inside Diameter (mm) | 63.5 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 2.75 |
| Outside Diameter (mm) | 63.5 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.74 |
2-1/4X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 64 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 2.25 |
| Hose Inside Diameter (mm) | 57.2 |
| Hose Outside Diameter (in) | 2.5 |
| Hose Outside Diameter (mm) | 63.5 |
| Inside Diameter (in) | 2.25 |
| Inside Diameter (mm) | 57.2 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 2.5 |
| Outside Diameter (mm) | 57.2 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.67 |
2-1/8X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 64 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 2.13 |
| Hose Inside Diameter (mm) | 54 |
| Hose Outside Diameter (in) | 2.31 |
| Hose Outside Diameter (mm) | 58.7 |
| Inside Diameter (in) | 2.13 |
| Inside Diameter (mm) | 54 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 2.31 |
| Outside Diameter (mm) | 54 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.63 |
2-3/4X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 7 |
| Minimum Bend Radius (mm) | 178 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 2.75 |
| Hose Inside Diameter (mm) | 69.9 |
| Hose Outside Diameter (in) | 3 |
| Hose Outside Diameter (mm) | 76.2 |
| Inside Diameter (in) | 2.75 |
| Inside Diameter (mm) | 69.9 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 3 |
| Outside Diameter (mm) | 69.9 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.81 |
2-3/8X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 64 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 2.38 |
| Hose Inside Diameter (mm) | 60.3 |
| Hose Outside Diameter (in) | 2.62 |
| Hose Outside Diameter (mm) | 66.5 |
| Inside Diameter (in) | 2.38 |
| Inside Diameter (mm) | 60.3 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 2.62 |
| Outside Diameter (mm) | 60.3 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.71 |
2-5/8X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 76 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 2.63 |
| Hose Inside Diameter (mm) | 66.7 |
| Hose Outside Diameter (in) | 2.88 |
| Hose Outside Diameter (mm) | 73.2 |
| Inside Diameter (in) | 2.63 |
| Inside Diameter (mm) | 66.7 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 2.88 |
| Outside Diameter (mm) | 66.7 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.78 |
3-1/2X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 7 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 10 |
| Minimum Bend Radius (mm) | 254 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 3.5 |
| Hose Inside Diameter (mm) | 88.9 |
| Hose Outside Diameter (in) | 3.75 |
| Hose Outside Diameter (mm) | 95.3 |
| Inside Diameter (in) | 3.5 |
| Inside Diameter (mm) | 88.9 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 3.75 |
| Outside Diameter (mm) | 88.9 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 1.01 |
3-1/8X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 7 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 10 |
| Minimum Bend Radius (mm) | 254 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 3.13 |
| Hose Inside Diameter (mm) | 79.4 |
| Hose Outside Diameter (in) | 3.38 |
| Hose Outside Diameter (mm) | 85.9 |
| Inside Diameter (in) | 3.13 |
| Inside Diameter (mm) | 79.4 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 3.38 |
| Outside Diameter (mm) | 79.4 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.92 |
3/4X10 AIR DUCT 20SD
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 1 |
| Minimum Bend Radius (mm) | 25 |
| Min. Burst Pressure (psi) | 80 |
| Hose Inside Diameter (in). | 0.75 |
| Hose Inside Diameter (mm) | 19.1 |
| Hose Outside Diameter (in) | 1 |
| Hose Outside Diameter (mm) | 25.4 |
| Inside Diameter (in) | 0.75 |
| Inside Diameter (mm) | 19.1 |
| Working Pressure (psi) | 20 |
| Length (m) | 3 |
| Outside Diameter (in) | 1 |
| Outside Diameter (mm) | 19.1 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.2 |
3X10 AIRDUCT 10SD
| Vacuum (In. Hg) | 7 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 10 |
| Minimum Bend Radius (mm) | 254 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 3 |
| Hose Inside Diameter (mm) | 76.2 |
| Hose Outside Diameter (in) | 3.25 |
| Hose Outside Diameter (mm) | 82.6 |
| Inside Diameter (in) | 3 |
| Inside Diameter (mm) | 76.2 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 3.25 |
| Outside Diameter (mm) | 76.2 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.88 |
4-1/2X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 7 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 12 |
| Minimum Bend Radius (mm) | 305 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 4.5 |
| Hose Inside Diameter (mm) | 114.3 |
| Hose Outside Diameter (in) | 4.75 |
| Hose Outside Diameter (mm) | 120.7 |
| Inside Diameter (in) | 4.5 |
| Inside Diameter (mm) | 114.3 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 4.75 |
| Outside Diameter (mm) | 114.3 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 1.25 |
4663A 2 1/4X50FT
No variation attributes.
4X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 7 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 12 |
| Minimum Bend Radius (mm) | 305 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 4 |
| Hose Inside Diameter (mm) | 101.6 |
| Hose Outside Diameter (in) | 4.25 |
| Hose Outside Diameter (mm) | 108 |
| Inside Diameter (in) | 4 |
| Inside Diameter (mm) | 101.6 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 4.25 |
| Outside Diameter (mm) | 101.6 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 1.15 |
5-1/2X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 6 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 12 |
| Minimum Bend Radius (mm) | 305 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 5.5 |
| Hose Inside Diameter (mm) | 139.7 |
| Hose Outside Diameter (in) | 5.75 |
| Hose Outside Diameter (mm) | 146.1 |
| Inside Diameter (in) | 5.5 |
| Inside Diameter (mm) | 139.7 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 5.75 |
| Outside Diameter (mm) | 139.7 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 1.52 |
5X10 AIR DUCT 10SD
| Vacuum (In. Hg) | 6 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 12 |
| Minimum Bend Radius (mm) | 305 |
| Min. Burst Pressure (psi) | 40 |
| Hose Inside Diameter (in). | 5 |
| Hose Inside Diameter (mm) | 127 |
| Hose Outside Diameter (in) | 5.25 |
| Hose Outside Diameter (mm) | 133.4 |
| Inside Diameter (in) | 5 |
| Inside Diameter (mm) | 127 |
| Working Pressure (psi) | 10 |
| Length (m) | 3 |
| Outside Diameter (in) | 5.25 |
| Outside Diameter (mm) | 127 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 1.4 |
6X10 AIR DUCT 8SD
| Vacuum (In. Hg) | 6 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 15 |
| Minimum Bend Radius (mm) | 381 |
| Min. Burst Pressure (psi) | 32 |
| Hose Inside Diameter (in). | 6 |
| Hose Inside Diameter (mm) | 152.4 |
| Hose Outside Diameter (in) | 6.25 |
| Hose Outside Diameter (mm) | 158.8 |
| Inside Diameter (in) | 6 |
| Inside Diameter (mm) | 152.4 |
| Working Pressure (psi) | 8 |
| Length (m) | 3 |
| Outside Diameter (in) | 6.25 |
| Outside Diameter (mm) | 152.4 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 1.7 |
7X10 PE 63SB
No variation attributes.
46634036
No variation attributes.
46630192
No variation attributes.
46633314
No variation attributes.
46633338
No variation attributes.
46633384
No variation attributes.
46633889
No variation attributes.
46630078
No variation attributes.
46633642
No variation attributes.
46634024
No variation attributes.
46633457
No variation attributes.
46633465
No variation attributes.
46634033
No variation attributes.
46632400
No variation attributes.
46633393
No variation attributes.
46633616
No variation attributes.
46633329
No variation attributes.
46633347
No variation attributes.
46633691
No variation attributes.
46634200
No variation attributes.
46633351
No variation attributes.
46633941
No variation attributes.
46634025
No variation attributes.
46633390
No variation attributes.
46634026
No variation attributes.
46633336
No variation attributes.
46633339
No variation attributes.
46633942
No variation attributes.
46633900
No variation attributes.
46631356
No variation attributes.
46633453
No variation attributes.
46634034
No variation attributes.
46634031
No variation attributes.
46633692
No variation attributes.
46633474
No variation attributes.
46633330
No variation attributes.
46630088
No variation attributes.
46633391
No variation attributes.
46633392
No variation attributes.
46631018
No variation attributes.
46633899
No variation attributes.
466300787
No variation attributes.
Specifications
| Vacuum (In. Hg) | 6 – 15 |
|---|---|
| Continuous Operating Temperature Range | -30°F to +250°F |
| Minimum Bend Radius (in) | 1 – 15 |
| Minimum Bend Radius (mm) | 25 – 381 |
| Min. Burst Pressure (psi) | 32 – 80 |
| Hose Inside Diameter (in). | 0.75 – 6 |
| Hose Inside Diameter (mm) | 19.1 – 152.4 |
| Hose Outside Diameter (in) | 1 – 6.25 |
| Hose Outside Diameter (mm) | 25.4 – 158.8 |
| Inside Diameter (in) | 0.75 – 6 |
| Inside Diameter (mm) | 19.1 – 152.4 |
| Working Pressure (psi) | 8 – 20 |
| Length (m) | 3 |
| Outside Diameter (in) | 1 – 6.25 |
| Outside Diameter (mm) | 19.1 – 152.4 |
| Color | Black |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube | Chloroprene - Type A. Oil Resistant. |
| Construction: Cover | Chloroprene - Type A |
| Recommended For | Heavy-duty heating and ventilating applications, such as air intake for butane conversion units, air and heater ducts, defroster lines, air cleaner connections to carburetor, exhaust ducts, vent lines for trailer sewers and drains. |
| Caution | Not recommended for conveying liquids. |
| Customer Pack | 10 |
| Weight (lbs.) | 0.2 – 1.7 |
PDF Documents
No PDF documents.
