Attributes
| Part Number | 8556-000000-000000 |
|---|
Description
Gates® Micro-V® Stretch Fit™ Belts Stretch Fit Drive Systems Demand Highly Engineered Solutions. Gates® Micro-V® Stretch Fit™ Belts, with exclusive self-tensioning technology, were the first Aftermarket belts engineered to fit like a glove and perform properly on these unique stretch fit drive systems and Gates continues to add coverage to this growing market segment. Gates engineered tensile cord has the needed combination of strength and flexibility using advanced polyamide tensile cord. Patented highly engineered EPDM belt ribs are extremely resistant to contamination, wear and pilling. Specially formulated adhesive literally locks on to the cord - allowing the cord to elongate and stretch, but never lose tension. Stretch Fit™ belts are single use only, and must be replaced if removed.
Variations (79)
K030305SF
No variation attributes.
K030308SF
No variation attributes.
K030331SF
No variation attributes.
K030340SF
No variation attributes.
K040233SF
No variation attributes.
K040299SF
No variation attributes.
K040318SF
No variation attributes.
K040331SF
No variation attributes.
K040344SF
No variation attributes.
K040345SF
No variation attributes.
K040433SF
No variation attributes.
K050354SF
No variation attributes.
K060265SF
No variation attributes.
K060306SF
No variation attributes.
K060429SF
No variation attributes.
K060667SF
| Effective Length (in) | 66.755 |
|---|---|
| Effective Length (mm) | 1696 |
| Outside Circumference (in) | 67.51 |
| Outside Circumference (mm) | 1715 |
| Top Width (in) | 0.807 |
| Top Width (mm) | 20 |
K030195SF
| Effective Length (in) | 19.5 |
|---|---|
| Effective Length (mm) | 495 |
| Outside Circumference (in) | 20 |
| Outside Circumference (mm) | 509 |
| Number of Ribs | 3 |
| Section | K |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
| Length (in) | 19.5 |
| Length (mm) | 495 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 93 |
| Weight (lbs.) | 0.05 |
K030196SF
| Effective Length (in) | 19.58 |
|---|---|
| Effective Length (mm) | 497 |
| Outside Circumference (in) | 20 |
| Outside Circumference (mm) | 508 |
| Number of Ribs | 3 |
| Section | K |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
| Length (in) | 19.58 |
| Length (mm) | 497 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 93 |
| Weight (lbs.) | 0.05 |
K030241SF
No variation attributes.
K030250SF
| Effective Length (in) | 25.04 |
|---|---|
| Effective Length (mm) | 636 |
| Outside Circumference (in) | 25.625 |
| Outside Circumference (mm) | 650 |
| Number of Ribs | 3 |
| Section | K |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
| Length (in) | 25.04 |
| Length (mm) | 636 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 50 |
| Weight (lbs.) | 0.08 |
K030266SF
No variation attributes.
K030293SF
| Effective Length (in) | 29.37 |
|---|---|
| Effective Length (mm) | 746 |
| Outside Circumference (in) | 29.875 |
| Outside Circumference (mm) | 759 |
| Number of Ribs | 3 |
| Section | K |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
| Length (in) | 29.37 |
| Length (mm) | 746 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 93 |
| Weight (lbs.) | 0.07 |
K030301SF
| Effective Length (in) | 30.18 |
|---|---|
| Effective Length (mm) | 767 |
| Outside Circumference (in) | 30.9 |
| Outside Circumference (mm) | 785 |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
K030303SF
| Effective Length (in) | 30.35 |
|---|---|
| Effective Length (mm) | 771 |
| Outside Circumference (in) | 30.88 |
| Outside Circumference (mm) | 784 |
| Number of Ribs | 3 |
| Section | K |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
| Length (in) | 30.35 |
| Length (mm) | 771 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 93 |
| Weight (lbs.) | 0.08 |
K030309SF
| Effective Length (in) | 30.98 |
|---|---|
| Effective Length (mm) | 787 |
| Outside Circumference (in) | 31.5 |
| Outside Circumference (mm) | 800 |
| Number of Ribs | 3 |
| Section | K |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
| Length (in) | 30.98 |
| Length (mm) | 787 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 93 |
| Weight (lbs.) | 0.08 |
K030311SF
No variation attributes.
K030315SF
| Effective Length (in) | 31.54 |
|---|---|
| Effective Length (mm) | 801 |
| Outside Circumference (in) | 32 |
| Outside Circumference (mm) | 813 |
| Number of Ribs | 3 |
| Section | K |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
| Length (in) | 31.54 |
| Length (mm) | 801 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 93 |
| Weight (lbs.) | 0.08 |
K030334SF
| Effective Length (in) | 33.45 |
|---|---|
| Effective Length (mm) | 850 |
| Outside Circumference (in) | 34 |
| Outside Circumference (mm) | 864 |
| Number of Ribs | 3 |
| Section | K |
| Top Width (in) | 0.42 |
| Top Width (mm) | 11 |
| Length (in) | 33.45 |
| Length (mm) | 850 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 93 |
| Weight (lbs.) | 0.08 |
K040245SF
| Effective Length (in) | 24.528 |
|---|---|
| Effective Length (mm) | 623 |
| Outside Circumference (in) | 25.125 |
| Outside Circumference (mm) | 638 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 24.528 |
| Length (mm) | 623 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.08 |
K040270SF
| Effective Length (in) | 27 |
|---|---|
| Effective Length (mm) | 686 |
| Outside Circumference (in) | 27.2 |
| Outside Circumference (mm) | 691 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 27 |
| Length (mm) | 686 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.09 |
K040289SF
| Effective Length (in) | 28.92 |
|---|---|
| Effective Length (mm) | 735 |
| Outside Circumference (in) | 29.5 |
| Outside Circumference (mm) | 749 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 28.92 |
| Length (mm) | 735 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.1 |
K040294SF
| Effective Length (in) | 29.49 |
|---|---|
| Effective Length (mm) | 749 |
| Outside Circumference (in) | 30 |
| Outside Circumference (mm) | 762 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 29.49 |
| Length (mm) | 749 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.1 |
K040296SF
| Effective Length (in) | 29.61 |
|---|---|
| Effective Length (mm) | 752 |
| Outside Circumference (in) | 30.125 |
| Outside Circumference (mm) | 765 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 29.61 |
| Length (mm) | 752 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.1 |
K040311SF
| Effective Length (in) | 31.1 |
|---|---|
| Effective Length (mm) | 790 |
| Outside Circumference (in) | 31.82 |
| Outside Circumference (mm) | 808 |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
K040315SF
| Effective Length (in) | 31.54 |
|---|---|
| Effective Length (mm) | 801 |
| Outside Circumference (in) | 31.13 |
| Outside Circumference (mm) | 816 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 31.52 |
| Length (mm) | 801 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.11 |
K040317SF
| Effective Length (in) | 31.73 |
|---|---|
| Effective Length (mm) | 806 |
| Outside Circumference (in) | 32.25 |
| Outside Circumference (mm) | 820 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 31.73 |
| Length (mm) | 806 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 50 |
| Weight (lbs.) | 0.15 |
K040323SF
| Effective Length (in) | 32.36 |
|---|---|
| Effective Length (mm) | 822 |
| Outside Circumference (in) | 32.875 |
| Outside Circumference (mm) | 835 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 32.36 |
| Length (mm) | 822 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.11 |
K040335SF
No variation attributes.
K040337SF
| Effective Length (in) | 33.78 |
|---|---|
| Effective Length (mm) | 858 |
| Outside Circumference (in) | 34.375 |
| Outside Circumference (mm) | 873 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 33.78 |
| Length (mm) | 858 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.11 |
K040338SF
| Effective Length (in) | 33.74 |
|---|---|
| Effective Length (mm) | 857 |
| Outside Circumference (in) | 34.25 |
| Outside Circumference (mm) | 870 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 33.74 |
| Length (mm) | 857 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.11 |
K040346SF
| Effective Length (in) | 34.67 |
|---|---|
| Effective Length (mm) | 881 |
| Outside Circumference (in) | 35.25 |
| Outside Circumference (mm) | 895 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 34.67 |
| Length (mm) | 881 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.12 |
K040352SF
| Effective Length (in) | 35.51 |
|---|---|
| Effective Length (mm) | 902 |
| Outside Circumference (in) | 35.875 |
| Outside Circumference (mm) | 912 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 35.51 |
| Length (mm) | 895 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 50 |
| Weight (lbs.) | 0.12 |
K040355SF
| Effective Length (in) | 35.51 |
|---|---|
| Effective Length (mm) | 902 |
| Outside Circumference (in) | 36 |
| Outside Circumference (mm) | 916 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 35.51 |
| Length (mm) | 902 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 50 |
| Weight (lbs.) | 0.15 |
K040356SF
| Effective Length (in) | 35.66 |
|---|---|
| Effective Length (mm) | 906 |
| Outside Circumference (in) | 36.25 |
| Outside Circumference (mm) | 920 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 35.66 |
| Length (mm) | 906 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.15 |
K040357SF
| Effective Length (in) | 35.76 |
|---|---|
| Effective Length (mm) | 908 |
| Outside Circumference (in) | 36.25 |
| Outside Circumference (mm) | 922 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 35.76 |
| Length (mm) | 908 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 150 |
| Weight (lbs.) | 0.15 |
K040358SF
| Effective Length (in) | 35.72 |
|---|---|
| Effective Length (mm) | 907 |
| Outside Circumference (in) | 36.25 |
| Outside Circumference (mm) | 921 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 35.72 |
| Length (mm) | 907 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.12 |
K040359SF
| Effective Length (in) | 35.91 |
|---|---|
| Effective Length (mm) | 912 |
| Outside Circumference (in) | 36.5 |
| Outside Circumference (mm) | 927 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 35.91 |
| Length (mm) | 912 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.12 |
K040360SF
| Effective Length (in) | 36.024 |
|---|---|
| Effective Length (mm) | 915 |
| Outside Circumference (in) | 36.625 |
| Outside Circumference (mm) | 930 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 36.024 |
| Length (mm) | 915 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.12 |
K040362SF
| Effective Length (in) | 36.23 |
|---|---|
| Effective Length (mm) | 920 |
| Outside Circumference (in) | 36.75 |
| Outside Circumference (mm) | 934 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 36.23 |
| Length (mm) | 920 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.15 |
K040363SF
| Effective Length (in) | 36.39 |
|---|---|
| Effective Length (mm) | 924 |
| Outside Circumference (in) | 37 |
| Outside Circumference (mm) | 940 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 36.39 |
| Length (mm) | 924 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.12 |
K040364SF
| Effective Length (in) | 36.42 |
|---|---|
| Effective Length (mm) | 925 |
| Outside Circumference (in) | 37 |
| Outside Circumference (mm) | 940 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 36.42 |
| Length (mm) | 925 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.12 |
K040365SF
| Effective Length (in) | 36.58 |
|---|---|
| Effective Length (mm) | 929 |
| Outside Circumference (in) | 37.125 |
| Outside Circumference (mm) | 943 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 36.58 |
| Length (mm) | 929 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.12 |
K040367SF
No variation attributes.
K040372SF
| Effective Length (in) | 37.28 |
|---|---|
| Effective Length (mm) | 947 |
| Outside Circumference (in) | 37.88 |
| Outside Circumference (mm) | 962 |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
K040373SF
| Effective Length (in) | 37.3 |
|---|---|
| Effective Length (mm) | 947 |
| Outside Circumference (in) | 37.875 |
| Outside Circumference (mm) | 961 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 37.3 |
| Length (mm) | 947 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.15 |
K040374SF
| Effective Length (in) | 37.4 |
|---|---|
| Effective Length (mm) | 950 |
| Outside Circumference (in) | 38 |
| Outside Circumference (mm) | 966 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 37.4 |
| Length (mm) | 950 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.15 |
K040375SF
| Effective Length (in) | 37.519 |
|---|---|
| Effective Length (mm) | 953 |
| Outside Circumference (in) | 38.25 |
| Outside Circumference (mm) | 972 |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
K040389SF
| Effective Length (in) | 38.97 |
|---|---|
| Effective Length (mm) | 990 |
| Outside Circumference (in) | 39.5 |
| Outside Circumference (mm) | 1003 |
| Number of Ribs | 4 |
| Section | K |
| Top Width (in) | 0.56 |
| Top Width (mm) | 14 |
| Length (in) | 38.97 |
| Length (mm) | 990 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 70 |
| Weight (lbs.) | 0.13 |
K050264SF
| Effective Length (in) | 26.42 |
|---|---|
| Effective Length (mm) | 671 |
| Outside Circumference (in) | 26 |
| Outside Circumference (mm) | 685 |
| Number of Ribs | 5 |
| Section | K |
| Top Width (in) | 0.667 |
| Top Width (mm) | 17 |
| Length (in) | 26.42 |
| Length (mm) | 671 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 125 |
| Weight (lbs.) | 0.15 |
K050268SF
| Effective Length (in) | 26.89 |
|---|---|
| Effective Length (mm) | 683 |
| Outside Circumference (in) | 27.375 |
| Outside Circumference (mm) | 695 |
| Number of Ribs | 5 |
| Section | K |
| Top Width (in) | 0.667 |
| Top Width (mm) | 17 |
| Length (in) | 26.89 |
| Length (mm) | 683 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 59 |
| Weight (lbs.) | 0.11 |
K050272SF
| Effective Length (in) | 27.21 |
|---|---|
| Effective Length (mm) | 691 |
| Outside Circumference (in) | 27.75 |
| Outside Circumference (mm) | 705 |
| Number of Ribs | 5 |
| Section | K |
| Top Width (in) | 0.667 |
| Top Width (mm) | 17 |
| Length (in) | 27.21 |
| Length (mm) | 691 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 125 |
| Weight (lbs.) | 0.17 |
K050327SF
| Effective Length (in) | 32.716 |
|---|---|
| Effective Length (mm) | 831 |
| Outside Circumference (in) | 33.25 |
| Outside Circumference (mm) | 845 |
| Number of Ribs | 5 |
| Section | K |
| Top Width (in) | 0.667 |
| Top Width (mm) | 17 |
| Length (in) | 32.716 |
| Length (mm) | 831 |
| Installation Requirement | No Tool Required |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 59 |
| Weight (lbs.) | 0.13 |
K060281SF
No variation attributes.
K060335SF
| Effective Length (in) | 33.5 |
|---|---|
| Effective Length (mm) | 851 |
| Outside Circumference (in) | 34 |
| Outside Circumference (mm) | 864 |
| Number of Ribs | 6 |
| Section | K |
| Top Width (in) | 0.807 |
| Top Width (mm) | 20 |
| Length (in) | 33.5 |
| Length (mm) | 851 |
| Installation Requirement | 3 mm Zip Tie |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 49 |
| Weight (lbs.) | 0.16 |
K060392SF
| Effective Length (in) | 39.221 |
|---|---|
| Effective Length (mm) | 996 |
| Outside Circumference (in) | 39.75 |
| Outside Circumference (mm) | 1010 |
| Number of Ribs | 6 |
| Section | K |
| Top Width (in) | 0.807 |
| Top Width (mm) | 20 |
| Length (in) | 39.221 |
| Length (mm) | 996 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 49 |
| Weight (lbs.) | 0.19 |
K060396SF
No variation attributes.
K060397SF
| Effective Length (in) | 39.78 |
|---|---|
| Effective Length (mm) | 1010 |
| Outside Circumference (in) | 40.375 |
| Outside Circumference (mm) | 1026 |
| Number of Ribs | 6 |
| Section | K |
| Top Width (in) | 0.807 |
| Top Width (mm) | 20 |
| Length (in) | 39.78 |
| Length (mm) | 1010 |
| Installation Requirement | Special Installation Tool |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 49 |
| Weight (lbs.) | 0.19 |
K060402SF
No variation attributes.
85560096
No variation attributes.
85560097
No variation attributes.
85560094
No variation attributes.
85560092
No variation attributes.
854820053
No variation attributes.
85560095
No variation attributes.
85560093
No variation attributes.
854820013
No variation attributes.
85560090
No variation attributes.
85560091
No variation attributes.
854820043
No variation attributes.
Specifications
| Effective Length (in) | 19.5 – 66.755 |
|---|---|
| Effective Length (mm) | 495 – 1696 |
| Outside Circumference (in) | 20 – 67.51 |
| Outside Circumference (mm) | 508 – 1715 |
| Top Width (in) | 0.42 – 0.807 |
| Top Width (mm) | 11 – 20 |
| Number of Ribs | 3 – 6 |
| Section | K |
| Length (in) | 19.5 – 39.78 |
| Length (mm) | 495 – 1010 |
| Installation Requirement | 3 mm Zip Tie, Special Installation Tool, No Tool Required |
| Automotive Notes | Prior to installation, Stretch Fit belts are shorter than the actual working length, but once installed they automatically tension - maintaining the proper tension over the life of the belt and ensuring optimum load-carrying capacity. |
| Customer Pack | 49 – 150 |
| Weight (lbs.) | 0.05 – 0.19 |
PDF Documents
Automotive Stretch Fit™ Belts
Open PDF
