Attributes
| Part Number | 7412-000000-000004 |
|---|
Description
Integrated Thermostat Housings There are two types of integrated thermostat housings: MAP controlled and standard. Both improve temperature regulation and control to help engines operate more efficiently. As vehicles are increasingly equipped with integrated thermostat housings, Gates research, development, and engineering is leading the industry in aftermarket thermostat solutions to provide the best quality alternative to OE dealerships. Provides adaptive, on-demand engine cooling. Allows ECU to regulate engine temperatures. Improves temperature regulation & control. Lowers emissions & fuel consumption. Standard - All-in-one, bolt-on solution that includes everything needed for a complete job. Includes thermostat, insert, seal and housing. Same easy installation as Standard Integrated Thermostat Housings. Meets or exceeds OE standards for fit, construction, and performance. Category-leading vehicle coverage.
Variations (30)
33528
| Check Valve | true |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 0.979 |
| Outlet 1 Outside Diameter (in) | 1.22 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 85 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.34 |
33910
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.31 |
| Outlet 1 Outside Diameter (in) | 1.65 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 86 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.48 |
33911
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.42 |
| Outlet 1 Outside Diameter (in) | 1.62 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 92 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.48 |
33912
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.29 |
| Outlet 1 Outside Diameter (in) | 1.445 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.42 |
33930
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.45 |
| Outlet 1 Outside Diameter (in) | 1.65 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 87 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | false |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 0 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.58 |
33934
| Check Valve | false |
|---|---|
| Electric | true |
| Outlet 1 Inside Diameter (in) | 1.27 |
| Outlet 1 Outside Diameter (in) | 1.49 |
| Outlet 2 Inside Diameter (in) | 1.25 |
| Outlet 2 Outside Diameter (in) | 1.48 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 97 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | false |
| Number of Bolt Holes | 4 |
| Number of Jiggle Pins/Check Valves | 0 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.95 |
33935
| Check Valve | false |
|---|---|
| Electric | true |
| Outlet 1 Inside Diameter (in) | 1.3 |
| Outlet 1 Outside Diameter (in) | 1.51 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 105 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 4 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.75 |
33937
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.189 |
| Outlet 1 Outside Diameter (in) | 1.41 |
| Outlet 2 Inside Diameter (in) | 1.189 |
| Outlet 2 Outside Diameter (in) | 1.41 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 95 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 4 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.63 |
33939
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.067 |
| Outlet 1 Outside Diameter (in) | 1.3 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 88 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | false |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 0 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.74 |
33940
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.205 |
| Outlet 1 Outside Diameter (in) | 1.375 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 77 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.51 |
33949
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.08 |
| Outlet 1 Outside Diameter (in) | 1.34 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 78 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.48 |
33950
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.59 |
| Outlet 1 Outside Diameter (in) | 1.74 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 83 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | false |
| Number of Bolt Holes | 4 |
| Number of Jiggle Pins/Check Valves | 0 |
| Number of Seals | 0 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.41 |
33951
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.23 |
| Outlet 1 Outside Diameter (in) | 1.45 |
| Outlet 2 Inside Diameter (in) | 0.44 |
| Outlet 2 Outside Diameter (in) | 0.56 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 0 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.84 |
33953
| Electric | false |
|---|---|
| Outlet 1 Inside Diameter (in) | 1.3 |
| Outlet 1 Outside Diameter (in) | 1.68 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | false |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 0 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.95 |
33958
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.476 |
| Outlet 1 Outside Diameter (in) | 1.751 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 89 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.48 |
34041
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.23 |
| Outlet 1 Outside Diameter (in) | 1.46 |
| Outlet 2 Inside Diameter (in) | 0.43 |
| Outlet 2 Outside Diameter (in) | 0.57 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 0 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.51 |
34042
| Check Valve | false |
|---|---|
| Electric | true |
| Outlet 1 Inside Diameter (in) | 1.12 |
| Outlet 1 Outside Diameter (in) | 1.38 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 98 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.52 |
34043
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 0.547 |
| Outlet 1 Outside Diameter (in) | 0.745 |
| Outlet 2 Inside Diameter (in) | 1.096 |
| Outlet 2 Outside Diameter (in) | 1.308 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 91 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.34 |
34044
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 0.547 |
| Outlet 1 Outside Diameter (in) | 0.745 |
| Outlet 2 Inside Diameter (in) | 1.096 |
| Outlet 2 Outside Diameter (in) | 1.308 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.34 |
34045
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.261 |
| Outlet 1 Outside Diameter (in) | 1.564 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 86 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.71 |
34046
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.15 |
| Outlet 1 Outside Diameter (in) | 1.4 |
| Outlet 2 Inside Diameter (in) | 0.58 |
| Outlet 2 Outside Diameter (in) | 0.82 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.4 |
34047
| Check Valve | false |
|---|---|
| Electric | true |
| Outlet 1 Inside Diameter (in) | 0.765 |
| Outlet 1 Outside Diameter (in) | 0.983 |
| Outlet 2 Inside Diameter (in) | 1 |
| Outlet 2 Outside Diameter (mm) | 1 |
| Outlet 3 Inside Diameter (in) | 1 |
| Outlet 3 Outside Diameter (in) | 1.275 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 100 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | false |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 0 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.95 |
34048
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.05 |
| Outlet 1 Outside Diameter (in) | 1.25 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 78 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.64 |
34050
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 0.971 |
| Outlet 1 Outside Diameter (in) | 1.275 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 77 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.4 |
34051
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.141 |
| Outlet 1 Outside Diameter (in) | 1.353 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.17 |
34052
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 1.16 |
| Outlet 1 Outside Diameter (in) | 1.42 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.45 |
34055
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 0.489 |
| Outlet 1 Outside Diameter (in) | 0.748 |
| Outlet 2 Inside Diameter (in) | 1.4 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 82 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.74 |
34069
| Check Valve | false |
|---|---|
| Electric | false |
| Outlet 1 Inside Diameter (in) | 0.989 |
| Outlet 2 Inside Diameter (in) | 0.92 |
| Outlet 2 Outside Diameter (in) | 1.145 |
| Outlet 2 Outside Diameter (mm) | 1.0049999999999999 |
| Outlet 3 Inside Diameter (in) | 1.005 |
| Outlet 3 Outside Diameter (in) | 1.275 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 87 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | false |
| Number of Bolt Holes | 2 |
| Number of Jiggle Pins/Check Valves | 0 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.95 |
34245
| Check Valve | false |
|---|---|
| Electric | true |
| Outlet 1 Inside Diameter (in) | 1.255 |
| Outlet 1 Outside Diameter (in) | 1.517 |
| Outlet 2 Inside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (in) | 0 |
| Outlet 2 Outside Diameter (mm) | 0 |
| Outlet 3 Inside Diameter (in) | 0 |
| Outlet 3 Outside Diameter (in) | 0 |
| Outlet 4 Inside Diameter (in) | 0 |
| Outlet 4 Outside Diameter (in) | 0 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 105 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 3 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.52 |
34246
| Check Valve | false |
|---|---|
| Electric | true |
| Outlet 1 Inside Diameter (in) | 1.35 |
| Outlet 1 Outside Diameter (in) | 1.56 |
| Outlet 2 Inside Diameter (in) | 1.34 |
| Outlet 2 Outside Diameter (in) | 1.51 |
| Outlet 2 Outside Diameter (mm) | 0.8 |
| Outlet 3 Inside Diameter (in) | 0.8 |
| Outlet 3 Outside Diameter (in) | 1.05 |
| Outlet 4 Inside Diameter (in) | 0.73 |
| Outlet 4 Outside Diameter (in) | 0.87 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 97 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true |
| Number of Bolt Holes | 0 |
| Number of Jiggle Pins/Check Valves | 1 |
| Number of Seals | 0 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.95 |
Specifications
| Check Valve | true, false |
|---|---|
| Electric | false, true |
| Outlet 1 Inside Diameter (in) | 0.489 – 1.59 |
| Outlet 1 Outside Diameter (in) | 0.745 – 1.751 |
| Outlet 2 Inside Diameter (in) | 0 – 1.4 |
| Outlet 2 Outside Diameter (in) | 0 – 1.51 |
| Outlet 2 Outside Diameter (mm) | 0 – 1.0049999999999999 |
| Outlet 3 Inside Diameter (in) | 0 – 1.005 |
| Outlet 3 Outside Diameter (in) | 0 – 1.275 |
| Outlet 4 Inside Diameter (in) | 0 – 0.73 |
| Outlet 4 Outside Diameter (in) | 0 – 0.87 |
| Outlet 5 Inside Diameter (in) | 0 |
| Outlet 5 Outside Diameter (in) | 0 |
| Outlet 6 Inside Diameter (in) | 0 |
| Outlet 6 Outside Diameter (in) | 0 |
| Temperature (C) | 77 – 105 |
| Jiggle Pin | false |
| Jiggle Pin/Check Valve | true, false |
| Number of Bolt Holes | 0 – 4 |
| Number of Jiggle Pins/Check Valves | 0 – 1 |
| Number of Seals | 0 – 1 |
| Customer Pack | 1 |
| Weight (lbs.) | 0.17 – 0.95 |
PDF Documents
Thermostats and Caps
Open PDF
