Attributes
| Part Number | 3205-000000-000004 |
|---|
Description
# Plant Master™ XTreme™ 501 AR
RECOMMENDED FOR: Applications requiring a premium–quality, multi–purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra–long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance.
- Good weather and ozone resistance.
- CAUTION: Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component.
- All sizes except 1 1/2" and 2" are non-conductive (>1Megohm/in.).
- Storage and use may adversely affect electrical resistance.
- Meets MSHA Flame–resistant.
Variations (15)
24PM3700
| Vacuum (In. Hg) | 10 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 12 |
| Minimum Bend Radius (mm) | 305 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 1.5 |
| Hose Inside Diameter (mm) | 38.1 |
| Hose Outside Diameter (in) | 2.09 |
| Hose Outside Diameter (mm) | 53.1 |
| Inside Diameter (in) | 1.5 |
| Inside Diameter (mm) | 38.1 |
| Working Pressure (psi) | 501 |
| Length (m) | 30.5 |
| Outside Diameter (in) | 2.09 |
| Outside Diameter (mm) | 38.1 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Multi-ply, synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 100 |
| Weight (lbs.) | 0.96 |
20PM3700
| Vacuum (In. Hg) | 10 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 10 |
| Minimum Bend Radius (mm) | 254 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 1.25 |
| Hose Inside Diameter (mm) | 31.8 |
| Hose Outside Diameter (in) | 1.78 |
| Hose Outside Diameter (mm) | 45.2 |
| Inside Diameter (in) | 1.25 |
| Inside Diameter (mm) | 31.8 |
| Working Pressure (psi) | 501 |
| Length (m) | 91.4 |
| Outside Diameter (in) | 1.78 |
| Outside Diameter (mm) | 31.8 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 300 |
| Weight (lbs.) | 0.73 |
8PM3710
| Vacuum (In. Hg) | 25 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 5 |
| Minimum Bend Radius (mm) | 127 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 0.5 |
| Hose Inside Diameter (mm) | 12.7 |
| Hose Outside Diameter (in) | 0.89 |
| Hose Outside Diameter (mm) | 22.6 |
| Inside Diameter (in) | 0.5 |
| Inside Diameter (mm) | 12.7 |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 0.89 |
| Outside Diameter (mm) | 12.7 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 500 |
| Weight (lbs.) | 0.268 |
8PM3700
| Vacuum (In. Hg) | 25 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 5 |
| Minimum Bend Radius (mm) | 127 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 0.5 |
| Hose Inside Diameter (mm) | 12.7 |
| Hose Outside Diameter (in) | 0.89 |
| Hose Outside Diameter (mm) | 22.6 |
| Inside Diameter (in) | 0.5 |
| Inside Diameter (mm) | 12.7 |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 0.89 |
| Outside Diameter (mm) | 12.7 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 500 |
| Weight (lbs.) | 0.25 |
4PM3710
| Vacuum (In. Hg) | 30 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 76 |
| Min. Burst Pressure (psi) | 2004 |
| Hose Inside Diameter (in). | 0.25 |
| Hose Inside Diameter (mm) | 6.4 |
| Hose Outside Diameter (in) | 0.57 |
| Hose Outside Diameter (mm) | 14.5 |
| Inside Diameter (in) | 0.25 |
| Inside Diameter (mm) | 6.4 |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 0.57 |
| Outside Diameter (mm) | 6.4 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 500 |
| Weight (lbs.) | 0.12 |
4PM3700
| Vacuum (In. Hg) | 30 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 76 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 0.25 |
| Hose Inside Diameter (mm) | 6.4 |
| Hose Outside Diameter (in) | 0.57 |
| Hose Outside Diameter (mm) | 14.5 |
| Inside Diameter (in) | 0.25 |
| Inside Diameter (mm) | 6.4 |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 0.57 |
| Outside Diameter (mm) | 6.4 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 500 |
| Weight (lbs.) | 0.1496 |
16PM3700
| Vacuum (In. Hg) | 10 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 8 |
| Minimum Bend Radius (mm) | 203 |
| Hose Inside Diameter (in). | 1 |
| Hose Inside Diameter (mm) | 25.4 |
| Hose Outside Diameter (in) | 1.51 |
| Hose Outside Diameter (mm) | 38.4 |
| Inside Diameter (in) | 1 |
| Inside Diameter (mm) | 25.4 |
| Temperature Range | -40°F to +212°F (-40°C to +100°C) |
| Working Pressure (psi) | 501 |
| Length (m) | 121.9 |
| Outside Diameter (in) | 1.51 |
| Outside Diameter (mm) | 25.4 |
| Coupling Recommendation | 1 Long Shank. 3 Cast Brass or Zinc Short Shank. 4 Machined Brass Short Shank. 15 Interlocking, Washer Joint. 71 Permanent Swaged or Crimped. |
| Use | Industrial Hose |
| Color | Yellow |
| Cover | Carboxylated Nitrile - Type C4. |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Construction: Design Factor | 4:1 |
| Construction: Reinforcement | Synthetic textile |
| Construction: Tube | Nitrile - Type C. Black. High oil resistance |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Couplings Note | Select Ind Hose Coupling Reference Sheet link below for additional information. |
| Customer Pack | 400 |
| Weight (lbs.) | 0.57 |
32PM3700
| Vacuum (In. Hg) | 10 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 14 |
| Minimum Bend Radius (mm) | 356 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 2 |
| Hose Inside Diameter (mm) | 50.8 |
| Hose Outside Diameter (in) | 2.64 |
| Hose Outside Diameter (mm) | 67.1 |
| Inside Diameter (in) | 2 |
| Inside Diameter (mm) | 50.8 |
| Working Pressure (psi) | 501 |
| Length (m) | 30.5 |
| Outside Diameter (in) | 2.64 |
| Outside Diameter (mm) | 50.8 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Multi-ply, synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 100 |
| Weight (lbs.) | 1.35 |
32PM3701
| Vacuum (In. Hg) | 10 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 14 |
| Minimum Bend Radius (mm) | 356 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 2 |
| Hose Inside Diameter (mm) | 50.8 |
| Hose Outside Diameter (in) | 2.64 |
| Hose Outside Diameter (mm) | 67.1 |
| Inside Diameter (in) | 2 |
| Inside Diameter (mm) | 50.8 |
| Working Pressure (psi) | 501 |
| Length (m) | 61 |
| Outside Diameter (in) | 2.64 |
| Outside Diameter (mm) | 50.8 |
| Color | Yellow |
| Reinforcement | Multi-ply, synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 200 |
| Weight (lbs.) | 1.35 |
12PM3710
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 6 |
| Minimum Bend Radius (mm) | 152 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 0.75 |
| Hose Inside Diameter (mm) | 19.1 |
| Hose Outside Diameter (in) | 1.22 |
| Hose Outside Diameter (mm) | 31 |
| Inside Diameter (in) | 0.75 |
| Inside Diameter (mm) | 19.1 |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 1.22 |
| Outside Diameter (mm) | 19.1 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 500 |
| Weight (lbs.) | 0.449 |
12PM3704
| Vacuum (In. Hg) | 15 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 6 |
| Minimum Bend Radius (mm) | 152 |
| Hose Inside Diameter (in). | 0.75 |
| Hose Inside Diameter (mm) | 19.1 |
| Hose Outside Diameter (in) | 1.22 |
| Hose Outside Diameter (mm) | 31 |
| Inside Diameter (in) | 0.75 |
| Inside Diameter (mm) | 19.1 |
| Temperature Range | -40°F to +212°F (-40°C to +100°C) |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 1.22 |
| Outside Diameter (mm) | 19.1 |
| Coupling Recommendation | 1 Long Shank. 3 Cast Brass or Zinc Short Shank. 4 Machined Brass Short Shank. 15 Interlocking, Washer Joint. 71 Permanent Swaged or Crimped. |
| Use | Industrial Hose |
| Color | Yellow |
| Cover | Carboxylated Nitrile - Type C4. |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Construction: Design Factor | 4:1 |
| Construction: Reinforcement | Synthetic textile |
| Construction: Tube | Nitrile - Type C. Black. High oil resistance |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Couplings Note | Select Ind Hose Coupling Reference Sheet link below for additional information. |
| Customer Pack | 500 |
| Weight (lbs.) | 0.45 |
6PM3710
| Vacuum (In. Hg) | 25 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 76 |
| Min. Burst Pressure (psi) | 2000 |
| Hose Inside Diameter (in). | 0.38 |
| Hose Inside Diameter (mm) | 9.5 |
| Hose Outside Diameter (in) | 0.75 |
| Hose Outside Diameter (mm) | 19.1 |
| Inside Diameter (in) | 0.38 |
| Inside Diameter (mm) | 9.5 |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 0.75 |
| Outside Diameter (mm) | 9.5 |
| Use | Industrial Hose |
| Color | Yellow |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 500 |
| Weight (lbs.) | 0.2 |
6PM3700
| Vacuum (In. Hg) | 25 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 76 |
| Hose Inside Diameter (in). | 0.38 |
| Hose Inside Diameter (mm) | 9.5 |
| Hose Outside Diameter (in) | 0.75 |
| Hose Outside Diameter (mm) | 19.1 |
| Inside Diameter (in) | 0.38 |
| Inside Diameter (mm) | 9.5 |
| Temperature Range | -40°F to +212°F (-40°C to +100°C) |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 0.75 |
| Outside Diameter (mm) | 9.5 |
| Coupling Recommendation | 19 Standard Air Hose. 1 Long Shank. 3 Cast Brass or Zinc Short Shank. 4 Machined Brass Short Shank. 15 Interlocking, Washer Joint. |
| Use | Industrial Hose |
| Color | Yellow |
| Cover | Carboxylated Nitrile - Type C4. |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Construction: Design Factor | 4:1 |
| Construction: Reinforcement | Synthetic textile |
| Construction: Tube | Nitrile - Type C. Black. High oil resistance |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Couplings Note | Select Ind Hose Coupling Reference Sheet link below for additional information. |
| Customer Pack | 500 |
| Weight (lbs.) | 0.19225 |
12PM3703
| Vacuum (In. Hg) | 15 |
|---|---|
| Minimum Bend Radius (in) | 6 |
| Minimum Bend Radius (mm) | 152 |
| Inside Diameter (in) | 0.75 |
| Inside Diameter (mm) | 19.1 |
| Temperature Range | -40°F to +212°F (-40°C to +100°C) |
| Working Pressure (psi) | 501 |
| Length (m) | 152.4 |
| Outside Diameter (in) | 1.22 |
| Outside Diameter (mm) | 19.1 |
| Coupling Recommendation | 1 Long Shank. 3 Cast Brass or Zinc Short Shank. 4 Machined Brass Short Shank. 15 Interlocking, Washer Joint. 71 Permanent Swaged or Crimped. |
| Color | Black |
| Cover | Carboxylated Nitrile - Type C4. |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Construction: Design Factor | 4:1 |
| Construction: Reinforcement | Synthetic textile |
| Construction: Tube | Nitrile - Type C. Black. High oil resistance |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
1X450FT CL PLANT MASTER XTREME 501AR
No variation attributes.
Specifications
| Vacuum (In. Hg) | 10 – 30 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +212°F |
| Minimum Bend Radius (in) | 3 – 14 |
| Minimum Bend Radius (mm) | 76 – 356 |
| Min. Burst Pressure (psi) | 2000 – 2004 |
| Hose Inside Diameter (in). | 0.25 – 2 |
| Hose Inside Diameter (mm) | 6.4 – 50.8 |
| Hose Outside Diameter (in) | 0.57 – 2.64 |
| Hose Outside Diameter (mm) | 14.5 – 67.1 |
| Inside Diameter (in) | 0.25 – 2 |
| Inside Diameter (mm) | 6.4 – 50.8 |
| Working Pressure (psi) | 501 |
| Length (m) | 30.5 – 152.4 |
| Outside Diameter (in) | 0.57 – 2.64 |
| Outside Diameter (mm) | 6.4 – 50.8 |
| Use | Industrial Hose |
| Color | Yellow, Black |
| Reinforcement | Multi-ply, synthetic textile, Synthetic textile |
| Tube | Nitrile - Type C. High oil resistance. |
| Construction: Cover | Carboxylated Nitrile - Type C4 |
| Standards | All sizes except 1 1/2" and 2" are non-conductive (>1 Megohm/in.). Meets MSHA Flame-resistant. Storage and use may adversely affect electrical resistance. |
| Standards: Cover | ARPM Class A |
| Standards: Tube | ARPM Class A |
| Notes | NOTE: Pkg Code T = One piece continuous length reel. Pkg Code XX = Two piece reel, 50 ft increments, no length less than 50 ft. |
| Recommended For | Applications requiring a premium-quality, multi-purpose hose with superior abrasion resistance for air, oil and some chemical applications. Excellent durability for extra-long life in these applications: mining, air drill, construction, poultry plants and other severe service. Good weather and ozone resistance. |
| Caution | Due to 501 AR PSI working pressure, care should be taken to properly select couplings to match. Hose assembly working pressure is the working pressure of the lowest rated component. |
| Customer Pack | 100 – 500 |
| Weight (lbs.) | 0.12 – 1.35 |
| Temperature Range | -40°F to +212°F (-40°C to +100°C) |
| Coupling Recommendation | 1 Long Shank. 3 Cast Brass or Zinc Short Shank. 4 Machined Brass Short Shank. 15 Interlocking, Washer Joint. 71 Permanent Swaged or Crimped., 19 Standard Air Hose. 1 Long Shank. 3 Cast Brass or Zinc Short Shank. 4 Machined Brass Short Shank. 15 Interlocking, Washer Joint. |
| Cover | Carboxylated Nitrile - Type C4. |
| Construction: Design Factor | 4:1 |
| Construction: Reinforcement | Synthetic textile |
| Construction: Tube | Nitrile - Type C. Black. High oil resistance |
| Couplings Note | Select Ind Hose Coupling Reference Sheet link below for additional information. |
PDF Documents
No PDF documents.
