Attributes
| Part Number | 7250-000000-000032 |
|---|
Description
Copper Tubing Industrial Compression Recommended for hydraulic and pneumatic systems. Provides a low cost, easy to assemble solution that does not require flaring. Used with copper, aluminum and plastic tubing. Working pressure up to 2,800 psi depending on the tube size. Working pressure up to 2,800 psi depending on the tube size.
Variations (112)
10CTI-10CTI / G55400-1010
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| A2 Outside Diameter (in) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
10CTI-8FP / G55150-1008
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
10CTI-8MP / G55100-1008
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
10CTI-8MP90 / G55104-1008
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.26 |
10TS-CTI / G55050-0010
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
10TSI-CTI / G55040-0010
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
10TSN-CTI / G55060-0010
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
12CTI-12CTI / G55400-1212
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| A2 Outside Diameter (in) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.4 |
12CTI-12MP / G55100-1212
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 12 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.33 |
12CTI-12MP90 / G55104-1212
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.38 |
12CTI-8MP / G55100-1208
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.24 |
12TN-CTI-L / G55030-0012
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
12TS-CTI / G55050-0012
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
12TSI-CTI / G55040-0012
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.015 |
12TSN-CTI / G55060-0012
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
2CTI-1MP / G55100-0201
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 1 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2CTI-1MP90 / G55104-0201
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 1 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2CTI-2CTI / G55400-0202
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| A2 Outside Diameter (in) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2CTI-2FP / G55150-0202
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2CTI-2MP / G55100-0202
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2CTI-2MP90 / G55104-0202
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2MP-3CTI-3CTI / G55130-0203
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| A2 Outside Diameter (in) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
2MP-4CTI-4CTI / G55130-0204
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| A2 Outside Diameter (in) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
2TS-CTI / G55050-0002
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
2TSN-CTI / G55060-0002
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
3CTI-2FP / G55150-0302
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
3CTI-2FP90 / G55154-0302
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
3CTI-2MP / G55100-0302
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
3CTI-2MP-CV / G55028-0302
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
3CTI-2MP90 / G55104-0302
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
3CTI-3CTI / G55400-0303
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| A2 Outside Diameter (in) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
3CTI-3CTI-2MP / G55134-0302
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| A2 Outside Diameter (in) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.5 |
3CTI-3CTI-3CTI / G55450-0303
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| A2 Outside Diameter (in) | 4.7 |
| A3 Outside Diameter (in) | 3/16 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
3CTI-3CTI90 / G55404-0303
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| A2 Outside Diameter (in) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
3CTI-4MP / G55100-0304
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
3TN-CTI-L / G55030-0003
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
3TS-CTI / G55050-0003
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
3TSN-CTI / G55060-0003
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
4CTI-2FP / G55150-0402
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
4CTI-2FP90 / G55154-0402
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
4CTI-2MP / G55100-0402
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
4CTI-2MP-CV / G55028-0402
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
4CTI-2MP90 / G55104-0402
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4CTI-4CTI / G55400-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| A2 Outside Diameter (in) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4CTI-4CTI-2MP / G55134-0402
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| A2 Outside Diameter (in) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
4CTI-4CTI-4CTI / G55450-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| A2 Outside Diameter (in) | 6.4 |
| A3 Outside Diameter (in) | 1/4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
4CTI-4CTI-4MP / G55134-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| A2 Outside Diameter (in) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
4CTI-4CTI-BKHD / G55300-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| A2 Outside Diameter (in) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
4CTI-4FP / G55150-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4CTI-4MP / G55100-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4CTI-4MP90 / G55104-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
4MP-4CTI-4CTI / G55130-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| A2 Outside Diameter (in) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
4MP-6CTI-6CTI / G55130-0406
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| A2 Outside Diameter (in) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
4TN-CTI-L / G55030-0004
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
4TS-CTI / G55050-0004
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
4TSI-CTI / G55040-0004
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.001 |
4TSI-CTI / G55040-0004T
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
4TSN-CTI / G55060-0004
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
5CTI-2FP / G55150-0502
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
5CTI-2MP / G55100-0502
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
5CTI-2MP-CV / G55028-0502
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
5CTI-2MP90 / G55104-0502
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
5CTI-4FP / G55150-0504
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
5CTI-4MP / G55100-0504
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
5CTI-4MP90 / G55104-0504
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
5CTI-5CTI / G55400-0505
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| A2 Outside Diameter (in) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
5CTI-5CTI-2MP / G55134-0502
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| A2 Outside Diameter (in) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
5CTI-5CTI-5CTI / G55450-0505
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| A2 Outside Diameter (in) | 7.9 |
| A3 Outside Diameter (in) | 5/16 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
5CTI-5CTI90 / G55404-0505
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| A2 Outside Diameter (in) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
5TN-CTI-L / G55030-0005
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
5TS-CTI / G55050-0005
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
5TSI-CTI / G55040-0005
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
5TSN-CTI / G55060-0005
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
6CTI-2FP / G55150-0602
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
6CTI-2MP / G55100-0602
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
6CTI-2MP90 / G55104-0602
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
6CTI-4FP / G55150-0604
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
6CTI-4FP90 / G55154-0604
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
6CTI-4MP / G55100-0604
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
6CTI-4MP-CV / G55028-0604
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
6CTI-4MP90 / G55104-0604
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
6CTI-6CTI / G55400-0606
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| A2 Outside Diameter (in) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
6CTI-6CTI-4MP / G55134-0604
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| A2 Outside Diameter (in) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
6CTI-6CTI-6CTI / G55450-0606
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| A2 Outside Diameter (in) | 9.5 |
| A3 Outside Diameter (in) | 3/8 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.16 |
6CTI-6CTI90 / G55404-0606
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| A2 Outside Diameter (in) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
6CTI-6MP / G55100-0606
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
6CTI-6MP90 / G55104-0606
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
6CTI-8MP / G55100-0608
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
6CTI-8MP90 / G55104-0608
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
6TN-CTI-L / G55030-0006
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
6TS-CTI / G55050-0006
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
6TSI-CTI / G55040-0006
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
6TSN-CTI / G55060-0006
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
7CTI-4MP / G55100-0704
| A1 Outside Diameter (in) | 0.4375 |
|---|---|
| A1 Outside Diameter (mm) | 11.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
7TS-CTI / G55050-0007
| A1 Outside Diameter (in) | 0.4375 |
|---|---|
| A1 Outside Diameter (mm) | 11.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.011 |
7TSN-CTI / G55060-0007
| A1 Outside Diameter (in) | 0.4375 |
|---|---|
| A1 Outside Diameter (mm) | 11.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
8CTI-4MP / G55100-0804
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
8CTI-4MP90 / G55104-0804
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.25 |
8CTI-6FP / G55150-0806
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
8CTI-6FP90 / G55154-0806
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
8CTI-6MP / G55100-0806
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
8CTI-6MP90 / G55104-0806
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.16 |
8CTI-8CTI / G55400-0808
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| A2 Outside Diameter (in) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
8CTI-8CTI-6MP / G55134-0806
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| A2 Outside Diameter (in) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
8CTI-8CTI-8CTI / G55450-0808
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| A2 Outside Diameter (in) | 12.7 |
| A3 Outside Diameter (in) | 1/2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.28 |
8CTI-8CTI90 / G55404-0808
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| A2 Outside Diameter (in) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
8CTI-8MP / G55100-0808
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
8CTI-8MP90 / G55104-0808
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.25 |
8TN-CTI-L / G55030-0008
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
8TS-CTI / G55050-0008
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.25 |
8TSI-CTI / G55040-0008
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
8TSN-CTI / G55060-0008
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
Specifications
| A1 Outside Diameter (in) | 0.125 – 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 – 19.1 |
| A2 Outside Diameter (in) | 3.2 – 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.001 – 0.5 |
| End 1 Diameter (mm) | 1 – 12 |
| Angle. | 90 |
| A3 Outside Diameter (in) | 3/16, 1/4, 5/16, 3/8, 1/2 |
PDF Documents
No PDF documents.
