Attributes
| Part Number | 7250-000000-000078 |
|---|
Description
Single Bead Couplings Recommended for low pressure fuel, oil, compressed air and water lines used in small engines, vacuum advance and evaporative emission control systems. Use with low pressure hose such as multi-purpose or general purpose hose. Single bead fittings are quick connecting, field attachable and reusable. Temperature Range: -40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C).
Variations (47)
G37100-1012
| T1 Thread (in) | 3/4-14 |
|---|---|
| A1 Outside Diameter (in) | 0.625 |
| A1 Outside Diameter (mm) | 15.9 |
| L Length (in) | 1.92 |
| L Length (mm) | 48.8 |
| L (in) | 1.92 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
G37100-1006
| T1 Thread (in) | 3/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.625 |
| A1 Outside Diameter (mm) | 15.9 |
| L Length (in) | 1.78 |
| L Length (mm) | 45.2 |
| L (in) | 1.78 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
G37106-1006
| T1 Thread (in) | 3/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.625 |
| A1 Outside Diameter (mm) | 15.9 |
| L Length (in) | 1.13 |
| L Length (mm) | 28.7 |
| L (in) | 1.13 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
G37100-1008
| T1 Thread (in) | 1/2-14 |
|---|---|
| A1 Outside Diameter (in) | 0.625 |
| A1 Outside Diameter (mm) | 15.9 |
| L Length (in) | 1.78 |
| L Length (mm) | 45.2 |
| L (in) | 1.78 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
G37106-1008
| T1 Thread (in) | 1/2-14 |
|---|---|
| A1 Outside Diameter (in) | 0.625 |
| A1 Outside Diameter (mm) | 15.9 |
| L Length (in) | 1.21 |
| L Length (mm) | 30.7 |
| L (in) | 1.21 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.22 |
G37100-1212
| T1 Thread (in) | 3/4-14 |
|---|---|
| A1 Outside Diameter (in) | 0.75 |
| A1 Outside Diameter (mm) | 19.1 |
| L Length (in) | 1.92 |
| L Length (mm) | 48.8 |
| L (in) | 1.92 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
G37100-1208
| T1 Thread (in) | 1/2-14 |
|---|---|
| A1 Outside Diameter (in) | 0.75 |
| A1 Outside Diameter (mm) | 19.1 |
| L Length (in) | 1.78 |
| L Length (mm) | 45.2 |
| L (in) | 1.78 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
G37106-1208
| T1 Thread (in) | 1/2-14 |
|---|---|
| A1 Outside Diameter (in) | 0.75 |
| A1 Outside Diameter (mm) | 19.1 |
| L Length (in) | 1.28 |
| L Length (mm) | 32.5 |
| L (in) | 1.28 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.25 |
G37100-0302
| T1 Thread (in) | 1/8-27 |
|---|---|
| A1 Outside Diameter (in) | 0.1875 |
| A1 Outside Diameter (mm) | 4.7 |
| L Length (in) | 1.26 |
| L Length (mm) | 32 |
| L (in) | 1.26 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
G37100-0402
| T1 Thread (in) | 1/8-27 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| L Length (in) | 1.32 |
| L Length (mm) | 33.5 |
| L (in) | 1.32 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
G37106-0402
| T1 Thread (in) | 1/8-27 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| L Length (in) | 1 |
| L Length (mm) | 25.4 |
| L (in) | 1 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37500-0404
| T1 Thread (in) | 7/16-24 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| L Length (in) | 1.72 |
| L Length (mm) | 43.7 |
| L (in) | 1.72 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.011 |
G37504-0404
| T1 Thread (in) | 7/16-24 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| L Length (in) | 1.01 |
| L Length (mm) | 25.7 |
| L (in) | 1.01 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
G37100-0404
| T1 Thread (in) | 1/4-18 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| L Length (in) | 1.63 |
| L Length (mm) | 41.4 |
| L (in) | 1.63 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37500-0405
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| L Length (in) | 1.78 |
| L Length (mm) | 45.2 |
| L (in) | 1.78 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37504-0405
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| L Length (in) | 1.01 |
| L Length (mm) | 25.7 |
| L (in) | 1.01 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
G37100-0502
| T1 Thread (in) | 1/8-27 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| L Length (in) | 1.55 |
| L Length (mm) | 39.4 |
| L (in) | 1.55 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
G37106-0502
| T1 Thread (in) | 1/8-27 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| L Length (in) | 1.01 |
| L Length (mm) | 25.7 |
| L (in) | 1.01 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37500-0504
| T1 Thread (in) | 7/16-24 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| L Length (in) | 1.58 |
| L Length (mm) | 40.1 |
| L (in) | 1.58 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37100-0504
| T1 Thread (in) | 1/4-18 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| L Length (in) | 1.55 |
| L Length (mm) | 39.4 |
| L (in) | 1.55 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37106-0504
| T1 Thread (in) | 1/4-18 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| L Length (in) | 1.01 |
| L Length (mm) | 25.7 |
| L (in) | 1.01 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
G37508-0505
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| L Length (in) | 2.03 |
| L Length (mm) | 51.6 |
| L (in) | 2.03 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37500-0505
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| L Length (in) | 1.58 |
| L Length (mm) | 40.1 |
| L (in) | 1.58 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
5SB-5RMIX90
No variation attributes.
G37500-0506
| T1 Thread (in) | 5/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| L Length (in) | 1.63 |
| L Length (mm) | 41.4 |
| L (in) | 1.63 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
G37103-0610
| T1 Thread (in) | 5/8-20 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
G37103-0614
| T1 Thread (in) | 7/8-20 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
G37100-0602
| T1 Thread (in) | 1/8-27 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.55 |
| L Length (mm) | 39.4 |
| L (in) | 1.55 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37106-0602
| T1 Thread (in) | 1/8-27 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.01 |
| L Length (mm) | 25.7 |
| L (in) | 1.01 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37100-0604
| T1 Thread (in) | 1/4-18 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.63 |
| L Length (mm) | 41.4 |
| L (in) | 1.63 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37106-0604
| T1 Thread (in) | 1/4-18 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.04 |
| L Length (mm) | 26.4 |
| L (in) | 1.04 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
G37508-0605
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 2.09 |
| L Length (mm) | 53.1 |
| L (in) | 2.09 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37500-0605
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.73 |
| L Length (mm) | 44 |
| L (in) | 1.73 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37503-0605
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.25 |
| L Length (mm) | 31.8 |
| L (in) | 1.25 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
G37504-0605
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.21 |
| L Length (mm) | 30.7 |
| L (in) | 1.21 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
G37195-0605
| T1 Thread (in) | 1/2-20 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 2 |
| L Length (mm) | 50.8 |
| L (in) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37508-0606
| T1 Thread (in) | 5/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 2.16 |
| L Length (mm) | 54.9 |
| L (in) | 2.16 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37500-0606
| T1 Thread (in) | 5/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 2 |
| L Length (mm) | 50.8 |
| L (in) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
G37504-0606
| T1 Thread (in) | 5/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.4 |
| L Length (mm) | 35.6 |
| L (in) | 1.4 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
G37100-0606
| T1 Thread (in) | 3/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.72 |
| L Length (mm) | 43.7 |
| L (in) | 1.72 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
G37106-0606
| T1 Thread (in) | 3/8-14 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 1.08 |
| L Length (mm) | 27.4 |
| L (in) | 1.08 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
G37195-0606
| T1 Thread (in) | 5/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| L Length (in) | 2 |
| L Length (mm) | 50.8 |
| L (in) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37103-0609
| T1 Thread (in) | 9/16-24 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
G37100-0806
| T1 Thread (in) | 3/8-18 |
|---|---|
| A1 Outside Diameter (in) | 0.5 |
| A1 Outside Diameter (mm) | 12.7 |
| L Length (in) | 1.72 |
| L Length (mm) | 43.7 |
| L (in) | 1.72 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
G37106-0806
| T1 Thread (in) | 3/8-14 |
|---|---|
| A1 Outside Diameter (in) | 0.5 |
| A1 Outside Diameter (mm) | 12.7 |
| L Length (in) | 1.08 |
| L Length (mm) | 27.4 |
| L (in) | 1.08 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
G37100-0808
| T1 Thread (in) | 1/2-14 |
|---|---|
| A1 Outside Diameter (in) | 0.5 |
| A1 Outside Diameter (mm) | 12.7 |
| L Length (in) | 1.79 |
| L Length (mm) | 45.5 |
| L (in) | 1.79 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
G37106-0808
| T1 Thread (in) | 1/2-14 |
|---|---|
| A1 Outside Diameter (in) | 0.5 |
| A1 Outside Diameter (mm) | 12.7 |
| L Length (in) | 1.16 |
| L Length (mm) | 29.5 |
| L (in) | 1.16 |
| Angle. | 90 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.25 |
Specifications
| T1 Thread (in) | 3/4-14, 3/8-18, 1/2-14, 1/8-27, 7/16-24, 1/4-18, +6 more |
|---|---|
| A1 Outside Diameter (in) | 0.1875 – 0.75 |
| A1 Outside Diameter (mm) | 4.7 – 19.1 |
| L Length (in) | 1 – 2.16 |
| L Length (mm) | 25.4 – 54.9 |
| L (in) | 1 – 2.16 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.011 – 0.25 |
| Angle. | 90 |
PDF Documents
No PDF documents.
