Attributes
| Part Number | 7480-000000-000021 |
|---|
Description
# Gates® Hose Cutter Model 1.25" 4 Wire Shop Saw
Powerful high-torque cutting saw for cutting wire braid and spiral hydraulic hose. Provides effortless and straight cuts every time.
- For four-wire spiral and two-braid hose up to 1.25" I.D.
- Power Source: 1 1/2 hp, 115V, 60Hz, 20A motor with Power Cord and Plug.
- Replacement Blade 7482-0045
## Features and Benefits
- Radius hose feed into blade for safety and reduced friction.
- Clean Easy Cuts - Safe Operation.
- 7" Metal Advanced Scalloped Blade specifically designed to cut hydraulic hose with 3/4" arbor.
- Cuts up 1 1/4" 4 Wire Spiral Hose.
- Inner Blade guard for safe operation.
- Operates on standard 115V 20A Service.
- Operates at 3430 RPM.
Variations (1)
1 1/4" 4SW SHOP SAW 60HZ 115V / 78088
| Specifications | Dimensions: 22" wide x 13" deep x 16" tall |
|---|---|
| Color | Blue |
| Customer Pack | 1 |
| Weight (lbs.) | 46.0 |
Specifications
| Specifications | Dimensions: 22" wide x 13" deep x 16" tall |
|---|---|
| Color | Blue |
| Customer Pack | 1 |
| Weight (lbs.) | 46.0 |
