Attributes
| Part Number | 7250-000000-000042 |
|---|
Description
Inverted Flare Recommended for hydraulic brake, fuel and oil lines, refrigerant in engine, air conditioning, marine and mobile applications. Products for use in LP and natural gas applications require special order. An economical and reusable solution that can be field installed. Threads and seats can be assembled and disassembled for long service life. Tighter tube bends can be achieved using a short nut (brass or steel), whereas a long nut is recommended in applications where excessive, high vibration exists. Used with copper, brass, aluminum and steel tubing that can be flared. An economical and reusable solution that can be field installed. Threads and seats can be assembled and disassembled for long service life. Tighter tube bends can be achieved using a short nut (brass or steel), whereas a long nut is recommended in applications where excessive, high vibration exists. Meets functional requirements of SAE J512 and specifications/standards of ASA, ASME, SAE and MS (Military Standards).
Metals Made to Your Application Specifications. With Gates® MachineWorks services, we work with you or your facility manager to customize drive components in a variety of bores, styles, materials, and finishes for your non-standard and prototype power transmission and belt drive applications.
Variations (100)
10FI-10FI / G60693-1010
| End 2 Diameter (mm) | 10 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 10 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.22 |
10T-10MIXN-S / G60596-1010
| A1 Outside Diameter (in) | 0.625 |
|---|---|
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 10 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
12MP-12FI / G60625-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| A1 Outside Diameter (in) | 0.75 |
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 12 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.22 |
12MP-12FI90 / G60627-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.48 |
12MP-14FI / G60625-1214
| End 2 Diameter (mm) | 14 |
|---|---|
| A1 Outside Diameter (in) | 0.875 |
| A1 Outside Diameter (mm) | 22.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 12 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.24 |
12MP-14FI90 / G60627-1214
| End 2 Diameter (mm) | 14 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.46 |
12T-12MIXN-S / G60596-1212
| A1 Outside Diameter (in) | 0.75 |
|---|---|
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 12 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
14FI-14FI-14FI / G60695-1414
| End 2 Diameter (mm) | 14 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 14 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.82 |
14T-14MIXN-S / G60596-1414
| A1 Outside Diameter (in) | 0.875 |
|---|---|
| A1 Outside Diameter (mm) | 22.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 14 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
16MP-16FI90 / G60627-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 16 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.84 |
16T-16MIXN-S / G60596-1616
| A1 Outside Diameter (in) | 1 |
|---|---|
| A1 Outside Diameter (mm) | 25.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 16 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
2FI-2FI / G60693-0202
| End 2 Diameter (mm) | 2 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2FI-2FI-2FI / G60695-0202
| End 2 Diameter (mm) | 2 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.74 |
2FP-2FI / G60630-0202
| End 2 Diameter (mm) | 2 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2FP-3FI / G60630-0203
| End 2 Diameter (mm) | 3 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2FP-4FI / G60630-0204
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2FP-5FI / G60630-0205
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2MP-2FI / G60625-0202
| End 2 Diameter (mm) | 2 |
|---|---|
| A1 Outside Diameter (in) | 0.125 |
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2MP-2FI45 / G60626-0202
| End 2 Diameter (mm) | 2 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 45 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2MP-2FI90 / G60627-0202
| End 2 Diameter (mm) | 2 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2MP-3FI / G60625-0203
| End 2 Diameter (mm) | 3 |
|---|---|
| A1 Outside Diameter (in) | 0.1875 |
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2MP-3FI-3FI / G60629-0203
| End 2 Diameter (mm) | 3 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
2MP-3FI45 / G60626-0203
| End 2 Diameter (mm) | 3 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 45 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2MP-3FI90 / G60627-0203
| End 2 Diameter (mm) | 3 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2MP-4FI / G60625-0204
| End 2 Diameter (mm) | 4 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
2MP-4FI-4FI / G60629-0204
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
2MP-4FI90 / G60627-0204
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2MP-5FI / G60625-0205
| End 2 Diameter (mm) | 5 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2MP-5FI-5FI / G60629-0205
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
2MP-5FI45 / G60626-0205
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 45 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2MP-5FI90 / G60627-0205
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
2MP-6FI / G60625-0206
| End 2 Diameter (mm) | 6 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
2MP-6FI45 / G60626-0206
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 45 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
2MP-6FI90 / G60627-0206
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 2 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
2T-2MIXN-S / G60596-0202
| A1 Outside Diameter (in) | 0.125 |
|---|---|
| A1 Outside Diameter (mm) | 3.2 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
3FI-3FI / G60693-0303
| End 2 Diameter (mm) | 3 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 3 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
3FI-3FI-2MP / G60628-0302
| End 2 Diameter (mm) | 3 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 3 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
3FI-3FI-3FI / G60695-0303
| End 2 Diameter (mm) | 3 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 3 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
3FI-3FI-3FP / G60696-0303
| End 2 Diameter (mm) | 3 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 3 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
3MI-PLUG / G60691-0003
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 3 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
3T-3MIXN-B / G60599-0303
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 3 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
3T-3MIXN-S / G60596-0303
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 3 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
3T-3MIXN-SL / G60597-0303
| A1 Outside Diameter (in) | 0.1875 |
|---|---|
| A1 Outside Diameter (mm) | 4.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 3 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
4FI-4FI / G60693-0404
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
4FI-4FI-2MP / G60628-0402
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4FI-4FI-4FI / G60695-0404
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
4FI-4FI-4FP / G60696-0404
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
4FI-4FI90 / G60694-0404
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4FP-4FI / G60630-0404
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.09 |
4FP-6FI / G60630-0406
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
4MI-PLUG / G60691-0004
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
4MP-4FI / G60625-0404
| End 2 Diameter (mm) | 4 |
|---|---|
| A1 Outside Diameter (in) | 0.25 |
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
4MP-4FI90 / G60627-0404
| End 2 Diameter (mm) | 4 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4MP-5FI / G60625-0405
| End 2 Diameter (mm) | 5 |
|---|---|
| A1 Outside Diameter (in) | 0.3125 |
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
4MP-5FI45 / G60626-0405
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 45 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4MP-5FI90 / G60627-0405
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
4MP-6FI / G60625-0406
| End 2 Diameter (mm) | 6 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4MP-6FI-6FI / G60629-0406
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.18 |
4MP-6FI90 / G60627-0406
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
4MP-8FI / G60625-0408
| End 2 Diameter (mm) | 8 |
|---|---|
| A1 Outside Diameter (in) | 0.5 |
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
4MP-8FI90 / G60627-0408
| End 2 Diameter (mm) | 8 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
4T-4MIXN-B / G60599-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.15 |
4T-4MIXN-S / G60596-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
4T-4MIXN-SL / G60597-0404
| A1 Outside Diameter (in) | 0.25 |
|---|---|
| A1 Outside Diameter (mm) | 6.4 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 4 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
5FI-5FI / G60693-0505
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
5FI-5FI-4MP / G60628-0504
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
5FI-5FI-5FI / G60695-0505
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
5FI-5FI-5FP / G60696-0505
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
5FI-5FI90 / G60694-0505
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
5MI-PLUG / G60691-0005
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
5T-5MIXN-B / G60599-0505
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 5 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
5T-5MIXN-S / G60596-0505
| A1 Outside Diameter (in) | 0.3125 |
|---|---|
| A1 Outside Diameter (mm) | 7.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 5 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 |
6FI-6FI / G60693-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
6FI-6FI-4FP / G60696-0604
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
6FI-6FI-4MP / G60628-0604
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
6FI-6FI90 / G60694-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
6FP-8FI / G60630-0608
| End 2 Diameter (mm) | 8 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
6MI-PLUG / G60691-0006
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
6MP-10FI90 / G60627-0610
| End 2 Diameter (mm) | 10 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.22 |
6MP-5FI90 / G60627-0605
| End 2 Diameter (mm) | 5 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
6MP-6FI / G60625-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| A1 Outside Diameter (in) | 0.375 |
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
6MP-6FI90 / G60627-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
6MP-7FI / G60625-0607
| End 2 Diameter (mm) | 7 |
|---|---|
| A1 Outside Diameter (in) | 0.4375 |
| A1 Outside Diameter (mm) | 11.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.08 |
6MP-8FI / G60625-0608
| End 2 Diameter (mm) | 8 |
|---|---|
| A1 Outside Diameter (in) | 0.5 |
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
6MP-8FI45 / G60626-0608
| End 2 Diameter (mm) | 8 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 45 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.12 |
6MP-8FI90 / G60627-0608
| End 2 Diameter (mm) | 8 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.16 |
6T-6MIXN-B / G60599-0606
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
6T-6MIXN-S / G60596-0606
| A1 Outside Diameter (in) | 0.375 |
|---|---|
| A1 Outside Diameter (mm) | 9.5 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 6 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
7T-7MIXN-S / G60596-0707
| A1 Outside Diameter (in) | 0.4375 |
|---|---|
| A1 Outside Diameter (mm) | 11.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 7 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
8FI-8FI / G60693-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.1 |
8FI-8FI-8FI / G60695-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.22 |
8MP-10FI / G60625-0810
| End 2 Diameter (mm) | 10 |
|---|---|
| A1 Outside Diameter (in) | 0.625 |
| A1 Outside Diameter (mm) | 15.9 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.16 |
8MP-10FI45 / G60626-0810
| End 2 Diameter (mm) | 10 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 45 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.2 |
8MP-10FI90 / G60627-0810
| End 2 Diameter (mm) | 10 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.25 |
8MP-12FI / G60625-0812
| End 2 Diameter (mm) | 12 |
|---|---|
| A1 Outside Diameter (in) | 0.75 |
| A1 Outside Diameter (mm) | 19.1 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.18 |
8MP-12FI90 / G60627-0812
| End 2 Diameter (mm) | 12 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.42 |
8MP-8FI / G60625-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| A1 Outside Diameter (in) | 0.5 |
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.14 |
8MP-8FI90 / G60627-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.26 |
8T-8MIXN-B / G60599-0808
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | 360 Brass |
| Customer Pack | 1 |
| Weight (lbs.) | 0.06 |
8T-8MIXN-S / G60596-0808
| A1 Outside Diameter (in) | 0.5 |
|---|---|
| A1 Outside Diameter (mm) | 12.7 |
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 8 |
| Material | Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.04 |
Specifications
| End 2 Diameter (mm) | 2 – 16 |
|---|---|
| Max. Working Pressure | 2000 |
| Max. Working Pressure (Bar) | 137.9 |
| End 1 Diameter (mm) | 2 – 16 |
| Material | 360 Brass, Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 – 0.84 |
| A1 Outside Diameter (in) | 0.125 – 1 |
| A1 Outside Diameter (mm) | 3.2 – 25.7 |
| Angle. | 45 – 90 |
PDF Documents
No PDF documents.
