Attributes
| Part Number | 7752-000000-000000 |
|---|
Description
# Conductive C14 PTFE Hose
C14 PTFE hose is recommended for air compressor discharge, hot oil and fluids, hot and greasy environments.
- Recommended for air compressor discharge, hot oil and fluids, hot and greasy environments.
- For use with Brass and Stainless Steel C14 Couplings [G40 Series].
- Hose and couplings can be crimped or swaged.
Hydraulics Catalog
Variations (4)
85730
| Dynamic WP (Max.psi) (1) | 1500 |
|---|---|
| Min. Burst Pressure (psi) 45F | 6000 |
| Min. Burst Pressure (psi) 72F | 10000 |
| Vacuum (In. Hg) | 28 |
| Working Pressure (psi) 45F | 1500 |
| Working Pressure (psi) 72F | 2500 |
| Continuous Operating Temperature Range | -65°F to +400°F |
| Minimum Bend Radius (in) | 4 |
| Minimum Bend Radius (mm) | 101.6 |
| Min. Burst Pressure (psi) | 6000 |
| Hose Inside Diameter (in). | 0.31 |
| Hose Inside Diameter (mm) | 7.9 |
| Hose Outside Diameter (in) | 0.45 |
| Hose Outside Diameter (mm) | 11.4 |
| Inside Diameter (in) | 0.3125 |
| Inside Diameter (mm) | 7.9 |
| Working Pressure (psi) | 1500 |
| Length (m) | 8 |
| Outside Diameter (in) | 0.45 |
| Outside Diameter (mm) | 11.4 |
| Use | Fleet |
| Color | Silver |
| Reinforcement | 1-braid, stainless steel |
| Tube | PTFE - Type B; White; Conductive, Smooth Bore |
| Construction: Cover | Stainless Steel Wire 304 |
| Standard Industry Specification | SAE 100R14 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Notes | 100R14 Type B. Static to +450°F. |
| Recommended For | Air compressor discharge, hot oil and fluids, hot and greasy environments. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.75 |
| Packaging | T |
70906
| Min. Burst Pressure (psi) 45F | 6000 |
|---|---|
| Min. Burst Pressure (psi) 72F | 10000 |
| Vacuum (In. Hg) | 28 |
| Working Pressure (psi) 45F | 1500 |
| Working Pressure (psi) 72F | 2500 |
| Continuous Operating Temperature Range | -65°F to +400°F |
| Minimum Bend Radius (in) | 4 |
| Minimum Bend Radius (mm) | 101.6 |
| Min. Burst Pressure (psi) | 1 |
| Hose Inside Diameter (in). | 0.312 |
| Hose Inside Diameter (mm) | 7.9 |
| Hose Outside Diameter (in) | 0.45 |
| Hose Outside Diameter (mm) | 11.4 |
| Inside Diameter (in) | 0.3125 |
| Inside Diameter (mm) | 7.9 |
| Working Pressure (psi) | 1500 |
| Length (m) | 91 |
| Outside Diameter (in) | 0.45 |
| Outside Diameter (mm) | 11.4 |
| Use | Fleet |
| Color | Silver |
| Reinforcement | 1-braid, stainless steel |
| Tube | PTFE - Type B; White; Conductive, Smooth Bore |
| Construction: Cover | Stainless Steel Wire 304 |
| Standard Industry Specification | SAE 100R14 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Notes | 100R14 Type B. Static to +450°F. |
| Recommended For | Air compressor discharge, hot oil and fluids, hot and greasy environments. |
| Customer Pack | 300 |
| Weight (lbs.) | 0.11 |
| Packaging | L |
85731
| Dynamic WP (Max.psi) (1) | 1000 |
|---|---|
| Min. Burst Pressure (psi) 45F | 4000 |
| Min. Burst Pressure (psi) 72F | 8000 |
| Vacuum (In. Hg) | 28 |
| Working Pressure (psi) 45F | 1000 |
| Working Pressure (psi) 72F | 2000 |
| Continuous Operating Temperature Range | -65°F to +400°F |
| Minimum Bend Radius (in) | 5.3 |
| Minimum Bend Radius (mm) | 134.6 |
| Min. Burst Pressure (psi) | 4000 |
| Hose Inside Diameter (in). | 0.41 |
| Hose Inside Diameter (mm) | 10.3 |
| Hose Outside Diameter (in) | 0.55 |
| Hose Outside Diameter (mm) | 14 |
| Inside Diameter (in) | 0.406 |
| Inside Diameter (mm) | 10.3 |
| Working Pressure (psi) | 1000 |
| Length (m) | 8 |
| Outside Diameter (in) | 0.55 |
| Outside Diameter (mm) | 14 |
| Use | Fleet |
| Color | Silver |
| Reinforcement | 1-braid, stainless steel |
| Tube | PTFE - Type B; White; Conductive, Smooth Bore |
| Construction: Cover | Stainless Steel Wire 304 |
| Standard Industry Specification | SAE 100R14 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Notes | 100R14 Type B. Static to +450°F. |
| Recommended For | Air compressor discharge, hot oil and fluids, hot and greasy environments. |
| Customer Pack | 1 |
| Weight (lbs.) | 3.0 |
| Packaging | T |
70908
| Dynamic WP (Max.psi) (1) | 1000 |
|---|---|
| Min. Burst Pressure (psi) 45F | 4000 |
| Min. Burst Pressure (psi) 72F | 8000 |
| Vacuum (In. Hg) | 28 |
| Working Pressure (psi) 45F | 1000 |
| Working Pressure (psi) 72F | 2000 |
| Continuous Operating Temperature Range | -65°F to +400°F |
| Minimum Bend Radius (in) | 5.3 |
| Minimum Bend Radius (mm) | 134.6 |
| Min. Burst Pressure (psi) | 4000 |
| Hose Inside Diameter (in). | 0.41 |
| Hose Inside Diameter (mm) | 10.3 |
| Hose Outside Diameter (in) | 0.55 |
| Hose Outside Diameter (mm) | 14 |
| Inside Diameter (in) | 0.406 |
| Inside Diameter (mm) | 10.3 |
| Working Pressure (psi) | 1000 |
| Length (m) | 76 |
| Outside Diameter (in) | 0.55 |
| Outside Diameter (mm) | 14 |
| Use | Fleet |
| Color | Silver |
| Reinforcement | 1-braid, stainless steel |
| Tube | PTFE - Type B; White; Conductive, Smooth Bore |
| Construction: Cover | Stainless Steel Wire 304 |
| Standard Industry Specification | SAE 100R14 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Notes | 100R14 Type B. Static to +450°F. |
| Recommended For | Air compressor discharge, hot oil and fluids, hot and greasy environments. |
| Customer Pack | 250 |
| Weight (lbs.) | 0.12 |
| Packaging | L |
Specifications
| Dynamic WP (Max.psi) (1) | 1000 – 1500 |
|---|---|
| Min. Burst Pressure (psi) 45F | 4000 – 6000 |
| Min. Burst Pressure (psi) 72F | 8000 – 10000 |
| Vacuum (In. Hg) | 28 |
| Working Pressure (psi) 45F | 1000 – 1500 |
| Working Pressure (psi) 72F | 2000 – 2500 |
| Continuous Operating Temperature Range | -65°F to +400°F |
| Minimum Bend Radius (in) | 4 – 5.3 |
| Minimum Bend Radius (mm) | 101.6 – 134.6 |
| Min. Burst Pressure (psi) | 1 – 6000 |
| Hose Inside Diameter (in). | 0.31 – 0.41 |
| Hose Inside Diameter (mm) | 7.9 – 10.3 |
| Hose Outside Diameter (in) | 0.45 – 0.55 |
| Hose Outside Diameter (mm) | 11.4 – 14 |
| Inside Diameter (in) | 0.3125 – 0.406 |
| Inside Diameter (mm) | 7.9 – 10.3 |
| Working Pressure (psi) | 1000 – 1500 |
| Length (m) | 8 – 91 |
| Outside Diameter (in) | 0.45 – 0.55 |
| Outside Diameter (mm) | 11.4 – 14 |
| Use | Fleet |
| Color | Silver |
| Reinforcement | 1-braid, stainless steel |
| Tube | PTFE - Type B; White; Conductive, Smooth Bore |
| Construction: Cover | Stainless Steel Wire 304 |
| Standard Industry Specification | SAE 100R14 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Notes | 100R14 Type B. Static to +450°F. |
| Recommended For | Air compressor discharge, hot oil and fluids, hot and greasy environments. |
| Customer Pack | 1 – 300 |
| Weight (lbs.) | 0.11 – 3.0 |
| Packaging | T, L |
