Attributes
| Part Number | 4657-000000-000036 |
|---|
Description
# IA3K - Wire Braid Hose - SAE 100R17
Gates PRO™ Series IA3K, 3000 psi constant-pressure hydraulic hoses deliver performance and reliability. Engineered for less demanding hydraulics applications, our line of professional-grade hoses are designed to balance product performance and investment for everyday uses. All sizes deliver consistent performance to SAE and ISO industry specifications.
- Recommended For: Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance.
- Qualified with Gates PRO™ Series and MegaCrimp™ Couplings.
- Ideal for non-severe, medium-pressure hydraulic applications with low flexure requirements.
- Meets SAE 100R17 and ISO 18752 Grade A.
- Constant 3,000 psi working pressure across all sizes to simplify system design.
- Manufactured to Gates high-quality professional standards.
- Meets MSHA Flame Resistance.
Variations (11)
10IA3K XREEL
| Minimum Bend Radius (in) | 4 |
|---|---|
| Minimum Bend Radius (mm) | 101.6 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.625 |
| Hose Inside Diameter (mm) | 15.9 |
| Hose Outside Diameter (in) | 0.97 |
| Hose Outside Diameter (mm) | 24.6 |
| Inside Diameter (in) | 0.625 |
| Inside Diameter (mm) | 15.9 |
| Working Pressure (psi) | 3000 |
| Length (m) | 67 |
| Outside Diameter (in) | 0.97 |
| Outside Diameter (mm) | 24.6 |
| Use | Wire Braid |
| Color | Black |
| Reinforcement | 1-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | SAE 100R17 ISO 18752 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers ISO - International Standards Organization |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 220 |
| Weight (lbs.) | 0.35 |
| Packaging | F |
12IA3K XBALE
| Continuous Operating Temperature Range | -40°F to +212°F |
|---|---|
| Minimum Bend Radius (in) | 4.8 |
| Minimum Bend Radius (mm) | 121.9 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.75 |
| Hose Inside Diameter (mm) | 19.1 |
| Hose Outside Diameter (in) | 1.1 |
| Hose Outside Diameter (mm) | 27.9 |
| Inside Diameter (in) | 0.75 |
| Inside Diameter (mm) | 19.1 |
| Working Pressure (psi) | 3000 |
| Length (m) | 381 |
| Outside Diameter (in) | 1.1 |
| Outside Diameter (mm) | 27.9 |
| Color | Black |
| Reinforcement | 1-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 1250 |
| Weight (lbs.) | 0.51 |
| Packaging | R |
12IA3K XREEL
| Continuous Operating Temperature Range | -40°F to +212°F |
|---|---|
| Minimum Bend Radius (in) | 4.8 |
| Minimum Bend Radius (mm) | 121.9 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.75 |
| Hose Inside Diameter (mm) | 19.1 |
| Hose Outside Diameter (in) | 1.1 |
| Hose Outside Diameter (mm) | 27.9 |
| Inside Diameter (in) | 0.75 |
| Inside Diameter (mm) | 19.1 |
| Working Pressure (psi) | 3000 |
| Length (m) | 67 |
| Outside Diameter (in) | 1.1 |
| Outside Diameter (mm) | 27.9 |
| Color | Black |
| Reinforcement | 2-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 220 |
| Weight (lbs.) | 0.51 |
| Packaging | F |
16IA3K XREEL
| Minimum Bend Radius (in) | 6 |
|---|---|
| Minimum Bend Radius (mm) | 152.4 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 1 |
| Hose Inside Diameter (mm) | 25.4 |
| Hose Outside Diameter (in) | 1.48 |
| Hose Outside Diameter (mm) | 37.6 |
| Inside Diameter (in) | 1 |
| Inside Diameter (mm) | 25.4 |
| Working Pressure (psi) | 3000 |
| Length (m) | 50 |
| Outside Diameter (in) | 1.48 |
| Outside Diameter (mm) | 37.6 |
| Color | Black |
| Reinforcement | 2-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | SAE 100R17 ISO 18752 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers ISO - International Standards Organization |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Customer Pack | 165 |
| Weight (lbs.) | 0.95 |
| Packaging | F |
4IA3K XBALE
| Continuous Operating Temperature Range | -40°F to +212°F |
|---|---|
| Minimum Bend Radius (in) | 2 |
| Minimum Bend Radius (mm) | 50.8 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.25 |
| Hose Inside Diameter (mm) | 6.4 |
| Hose Outside Diameter (in) | 0.47 |
| Hose Outside Diameter (mm) | 11.9 |
| Inside Diameter (in) | 0.25 |
| Inside Diameter (mm) | 6.4 |
| Working Pressure (psi) | 3000 |
| Length (m) | 2134 |
| Outside Diameter (in) | 0.47 |
| Outside Diameter (mm) | 11.9 |
| Color | Black |
| Reinforcement | 1-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 7000 |
| Weight (lbs.) | 0.12 |
| Packaging | R |
4IA3K XREEL
| Continuous Operating Temperature Range | -40°F to +212°F |
|---|---|
| Minimum Bend Radius (in) | 2 |
| Minimum Bend Radius (mm) | 50.8 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.25 |
| Hose Inside Diameter (mm) | 6.4 |
| Hose Outside Diameter (in) | 0.47 |
| Hose Outside Diameter (mm) | 11.9 |
| Inside Diameter (in) | 0.25 |
| Inside Diameter (mm) | 6.4 |
| Working Pressure (psi) | 3000 |
| Length (m) | 134 |
| Outside Diameter (in) | 0.47 |
| Outside Diameter (mm) | 11.9 |
| Color | Black |
| Reinforcement | 1-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 440 |
| Weight (lbs.) | 0.12 |
| Packaging | N |
6IA3K XBALE
| Continuous Operating Temperature Range | -40°F to +212°F |
|---|---|
| Minimum Bend Radius (in) | 2.5 |
| Minimum Bend Radius (mm) | 63.5 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.375 |
| Hose Inside Diameter (mm) | 9.5 |
| Hose Outside Diameter (in) | 0.63 |
| Hose Outside Diameter (mm) | 16 |
| Inside Diameter (in) | 0.375 |
| Inside Diameter (mm) | 9.5 |
| Working Pressure (psi) | 3000 |
| Length (m) | 1372 |
| Outside Diameter (in) | 0.63 |
| Outside Diameter (mm) | 16 |
| Color | Black |
| Reinforcement | 1-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 4500 |
| Weight (lbs.) | 0.19 |
| Packaging | R |
6IA3K XREEL
| Continuous Operating Temperature Range | -40°F to +212°F |
|---|---|
| Minimum Bend Radius (in) | 2.5 |
| Minimum Bend Radius (mm) | 63.5 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.375 |
| Hose Inside Diameter (mm) | 9.5 |
| Hose Outside Diameter (in) | 0.63 |
| Hose Outside Diameter (mm) | 16 |
| Inside Diameter (in) | 0.375 |
| Inside Diameter (mm) | 9.5 |
| Working Pressure (psi) | 3000 |
| Length (m) | 101 |
| Outside Diameter (in) | 0.63 |
| Outside Diameter (mm) | 16 |
| Color | Black |
| Reinforcement | 1-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 330 |
| Weight (lbs.) | 0.19 |
| Packaging | N |
8IA3K XBALE
| Continuous Operating Temperature Range | -40°F to +212°F |
|---|---|
| Minimum Bend Radius (in) | 3.5 |
| Minimum Bend Radius (mm) | 88.9 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.5 |
| Hose Inside Diameter (mm) | 12.7 |
| Hose Outside Diameter (in) | 0.76 |
| Hose Outside Diameter (mm) | 19.3 |
| Inside Diameter (in) | 0.5 |
| Inside Diameter (mm) | 12.7 |
| Working Pressure (psi) | 3000 |
| Length (m) | 854 |
| Outside Diameter (in) | 0.76 |
| Outside Diameter (mm) | 19.3 |
| Color | Black |
| Reinforcement | 1-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 2800 |
| Weight (lbs.) | 0.28 |
| Packaging | R |
8IA3K XREEL
| Continuous Operating Temperature Range | -40°F to +212°F |
|---|---|
| Minimum Bend Radius (in) | 3.5 |
| Minimum Bend Radius (mm) | 88.9 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.5 |
| Hose Inside Diameter (mm) | 12.7 |
| Hose Outside Diameter (in) | 0.76 |
| Hose Outside Diameter (mm) | 19.3 |
| Inside Diameter (in) | 0.5 |
| Inside Diameter (mm) | 12.7 |
| Working Pressure (psi) | 3000 |
| Length (m) | 67 |
| Outside Diameter (in) | 0.76 |
| Outside Diameter (mm) | 19.3 |
| Color | Black |
| Reinforcement | 1-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 220 |
| Weight (lbs.) | 0.28 |
| Packaging | N |
16IA3KX100CTN
No variation attributes.
Specifications
| Minimum Bend Radius (in) | 2 – 6 |
|---|---|
| Minimum Bend Radius (mm) | 50.8 – 152.4 |
| Min. Burst Pressure (psi) | 3 |
| Hose Inside Diameter (in). | 0.25 – 1 |
| Hose Inside Diameter (mm) | 6.4 – 25.4 |
| Hose Outside Diameter (in) | 0.47 – 1.48 |
| Hose Outside Diameter (mm) | 11.9 – 37.6 |
| Inside Diameter (in) | 0.25 – 1 |
| Inside Diameter (mm) | 6.4 – 25.4 |
| Working Pressure (psi) | 3000 |
| Length (m) | 50 – 2134 |
| Outside Diameter (in) | 0.47 – 1.48 |
| Outside Diameter (mm) | 11.9 – 37.6 |
| Use | Wire Braid |
| Color | Black |
| Reinforcement | 1-braid, wire, 2-braid, wire |
| Tube | Nitrile; Black; Hyd Fluids, Phosphate Esters, Water Glycol |
| Construction: Cover | Modified SBR |
| Standard Industry Specification | SAE 100R17 ISO 18752, ISO 18752, SAE 100R17 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers ISO - International Standards Organization, ISO - International Standards Organization, SAE - Society of Automotive Engineers |
| Notes | 18752 Class 210 Grade A100R17. Meets MSHA 2G. |
| Recommended For | Medium-pressure hydraulics with low flexure/non-severe applications requiring the SAE 100R17 or ISO 18752 Class 210 Grade A specification for dimensions and performance. |
| Customer Pack | 165 – 7000 |
| Weight (lbs.) | 0.12 – 0.95 |
| Packaging | F, R, N |
| Continuous Operating Temperature Range | -40°F to +212°F |
PDF Documents
IA3K Hydraulic Hose Brochure
Open PDF
