Attributes
| Part Number | 8701-000000-000000 |
|---|
Description
# Automotive XL V-Belts
The Automotive XL™ is a durable, heavy-duty replacement V-belt designed for the most demanding engine drives. Due to thermal forces in the vehicle engine, this variable notched belt tightens on the drive as it heats up to prevent slippage or belt loss, improve belt performance, and reduce noise.
- Fiber-loaded rubber stock adds flexibility along the length of the belt and provides greater lateral stability in the pulley.
- Form-ground to ensure precise top width and sidewall dimensional control for proper fit to the pulley.
- Thermally active tensile cords for maintenance-free performance when properly installed and tensioned.
- XL Belts resist oil, heat, ozone, weather, and aging for improved belt life.
- Meets or exceeds SAE J636C specifications.
## Precision = Performance
At Gates, our products are defined by the details. That's why we've spent years perfecting our manufacturing processes to an exact science, which we use in Gates manufacturing facilities all over the world to ensure interchangeability. Our Automotive XL V-Belts are manufactured with a patented, precision V-forming process assuring exact size and angle control for optimal performance on your vehicle’s specific make and model.
Variations (216)
7228
No variation attributes.
7370
No variation attributes.
7715
No variation attributes.
9341
No variation attributes.
9361M
No variation attributes.
9555
No variation attributes.
9580
No variation attributes.
7208
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 20.69 |
| Effective Length (mm) | 526 |
| Notched | true |
| Outside Circumference (in) | 21.54 |
| Outside Circumference (mm) | 547 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 275 |
| Weight (lbs.) | 0.1 |
7215
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 21.5 |
| Effective Length (mm) | 546 |
| Notched | true |
| Outside Circumference (in) | 22.35 |
| Outside Circumference (mm) | 568 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.12 |
7234
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 23.5 |
| Effective Length (mm) | 597 |
| Notched | false |
| Outside Circumference (in) | 23.82 |
| Outside Circumference (mm) | 605 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 38 |
| Thickness (in) | 0.25 |
| Thickness (mm) | 6 |
| Customer Pack | 325 |
| Weight (lbs.) | 0.09 |
7240
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 24 |
| Effective Length (mm) | 610 |
| Notched | true |
| Outside Circumference (in) | 24.58 |
| Outside Circumference (mm) | 624 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.13 |
7250
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 25 |
| Effective Length (mm) | 635 |
| Notched | true |
| Outside Circumference (in) | 25.84 |
| Outside Circumference (mm) | 650 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 850 |
| Weight (lbs.) | 0.13 |
7255
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 25.5 |
| Effective Length (mm) | 648 |
| Notched | true |
| Outside Circumference (in) | 26.34 |
| Outside Circumference (mm) | 669 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 20 |
| Weight (lbs.) | 0.14 |
7260
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 26 |
| Effective Length (mm) | 660 |
| Notched | true |
| Outside Circumference (in) | 26.84 |
| Outside Circumference (mm) | 682 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 850 |
| Weight (lbs.) | 0.14 |
7261
| Cross Section | HC25 |
|---|---|
| Effective Length (in) | 26.2 |
| Effective Length (mm) | 665 |
| Notched | false |
| Outside Circumference (in) | 26.2 |
| Outside Circumference (mm) | 665 |
| Strand | 1 |
| Top Width (in) | 0.265 |
| Top Width (mm) | 6 |
| Angle. | 36 |
| Thickness (in) | 0.22 |
| Thickness (mm) | 6 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.07 |
7265
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 26.5 |
| Effective Length (mm) | 673 |
| Notched | true |
| Outside Circumference (in) | 27.34 |
| Outside Circumference (mm) | 694 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 225 |
| Weight (lbs.) | 0.14 |
7270
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 27 |
| Effective Length (mm) | 686 |
| Notched | true |
| Outside Circumference (in) | 27.84 |
| Outside Circumference (mm) | 707 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.14 |
7280
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 28 |
| Effective Length (mm) | 711 |
| Notched | true |
| Outside Circumference (in) | 28.84 |
| Outside Circumference (mm) | 732.5 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.15 |
7290
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 29 |
| Effective Length (mm) | 737 |
| Notched | true |
| Outside Circumference (in) | 29.84 |
| Outside Circumference (mm) | 758 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.15 |
7292
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 29.25 |
| Effective Length (mm) | 743 |
| Notched | true |
| Outside Circumference (in) | 30.09 |
| Outside Circumference (mm) | 764 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 200 |
| Weight (lbs.) | 0.15 |
7295
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 29.5 |
| Effective Length (mm) | 749 |
| Notched | true |
| Outside Circumference (in) | 30.34 |
| Outside Circumference (mm) | 771 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.15 |
7300
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 30 |
| Effective Length (mm) | 762 |
| Notched | true |
| Outside Circumference (in) | 30.84 |
| Outside Circumference (mm) | 783 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.15 |
7304
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 30.48 |
| Effective Length (mm) | 774 |
| Notched | false |
| Outside Circumference (in) | 30.71 |
| Outside Circumference (mm) | 780 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 36 |
| Thickness (in) | 0.25 |
| Thickness (mm) | 6 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.11 |
7305
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 30.6 |
| Effective Length (mm) | 777 |
| Notched | true |
| Outside Circumference (in) | 31.44 |
| Outside Circumference (mm) | 798.5 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.16 |
7312
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 31 |
| Effective Length (mm) | 787 |
| Notched | true |
| Outside Circumference (in) | 31.84 |
| Outside Circumference (mm) | 809 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.16 |
7315
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 31.5 |
| Effective Length (mm) | 800 |
| Notched | true |
| Outside Circumference (in) | 32.34 |
| Outside Circumference (mm) | 821 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.16 |
7320
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 32 |
| Effective Length (mm) | 813 |
| Notched | true |
| Outside Circumference (in) | 32.84 |
| Outside Circumference (mm) | 834 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.16 |
7324
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 32.5 |
| Effective Length (mm) | 826 |
| Notched | false |
| Outside Circumference (in) | 32.68 |
| Outside Circumference (mm) | 830 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 38 |
| Thickness (in) | 0.24 |
| Thickness (mm) | 6 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.12 |
7325
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 32.5 |
| Effective Length (mm) | 826 |
| Notched | true |
| Outside Circumference (in) | 33.34 |
| Outside Circumference (mm) | 847 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.17 |
7328
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 32.75 |
| Effective Length (mm) | 832 |
| Notched | true |
| Outside Circumference (in) | 33.59 |
| Outside Circumference (mm) | 853 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.17 |
7329
| Cross Section | HC25 |
|---|---|
| Effective Length (in) | 33 |
| Effective Length (mm) | 838 |
| Notched | false |
| Outside Circumference (in) | 33.27 |
| Outside Circumference (mm) | 845 |
| Strand | 1 |
| Top Width (in) | 0.265 |
| Top Width (mm) | 6 |
| Angle. | 38 |
| Thickness (in) | 0.21 |
| Thickness (mm) | 5 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.09 |
7330
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 33 |
| Effective Length (mm) | 838 |
| Notched | true |
| Outside Circumference (in) | 33.84 |
| Outside Circumference (mm) | 853 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.17 |
7335
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 33.5 |
| Effective Length (mm) | 851 |
| Notched | true |
| Outside Circumference (in) | 34.34 |
| Outside Circumference (mm) | 872 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 20 |
| Weight (lbs.) | 0.17 |
7340
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 34 |
| Effective Length (mm) | 864 |
| Notched | true |
| Outside Circumference (in) | 34.84 |
| Outside Circumference (mm) | 885 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.17 |
7345
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 34.51 |
| Effective Length (mm) | 877 |
| Notched | true |
| Outside Circumference (in) | 35.35 |
| Outside Circumference (mm) | 898 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.18 |
7348
| Cross Section | HC25 |
|---|---|
| Effective Length (in) | 35 |
| Effective Length (mm) | 889 |
| Notched | false |
| Outside Circumference (in) | 35.24 |
| Outside Circumference (mm) | 895 |
| Strand | 1 |
| Top Width (in) | 0.265 |
| Top Width (mm) | 6 |
| Angle. | 38 |
| Thickness (in) | 0.21 |
| Thickness (mm) | 5 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.09 |
7350
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 34.99 |
| Effective Length (mm) | 889 |
| Notched | true |
| Outside Circumference (in) | 35.83 |
| Outside Circumference (mm) | 910 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 750 |
| Weight (lbs.) | 0.18 |
7355
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 35.6 |
| Effective Length (mm) | 904 |
| Notched | true |
| Outside Circumference (in) | 36.43 |
| Outside Circumference (mm) | 925 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 650 |
| Weight (lbs.) | 0.19 |
7359
| Cross Section | HC25 |
|---|---|
| Effective Length (in) | 36 |
| Effective Length (mm) | 914 |
| Notched | false |
| Outside Circumference (in) | 36.22 |
| Outside Circumference (mm) | 920 |
| Strand | 1 |
| Top Width (in) | 0.265 |
| Top Width (mm) | 6 |
| Angle. | 38 |
| Thickness (in) | 0.21 |
| Thickness (mm) | 5 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.1 |
7360
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 36 |
| Effective Length (mm) | 914 |
| Notched | true |
| Outside Circumference (in) | 36.83 |
| Outside Circumference (mm) | 935 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 650 |
| Weight (lbs.) | 0.19 |
7363
| Cross Section | HC25 |
|---|---|
| Effective Length (in) | 36.5 |
| Effective Length (mm) | 927 |
| Notched | false |
| Outside Circumference (in) | 36.81 |
| Outside Circumference (mm) | 935 |
| Strand | 1 |
| Top Width (in) | 0.265 |
| Top Width (mm) | 6 |
| Angle. | 38 |
| Thickness (in) | 0.21 |
| Thickness (mm) | 5 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.1 |
7365
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 36.5 |
| Effective Length (mm) | 927 |
| Notched | true |
| Outside Circumference (in) | 37.33 |
| Outside Circumference (mm) | 948 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 650 |
| Weight (lbs.) | 0.19 |
7369
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 37 |
| Effective Length (mm) | 940 |
| Notched | false |
| Outside Circumference (in) | 37.2 |
| Outside Circumference (mm) | 945 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 38 |
| Thickness (in) | 0.24 |
| Thickness (mm) | 6 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.14 |
7375
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 37.5 |
| Effective Length (mm) | 953 |
| Notched | true |
| Outside Circumference (in) | 38.33 |
| Outside Circumference (mm) | 973.5 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 650 |
| Weight (lbs.) | 0.2 |
7380
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 37.98 |
| Effective Length (mm) | 965 |
| Notched | true |
| Outside Circumference (in) | 38.81 |
| Outside Circumference (mm) | 985 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 650 |
| Weight (lbs.) | 0.2 |
7381
| Cross Section | HC25 |
|---|---|
| Effective Length (in) | 38 |
| Effective Length (mm) | 965 |
| Notched | false |
| Outside Circumference (in) | 38.19 |
| Outside Circumference (mm) | 970 |
| Strand | 1 |
| Top Width (in) | 0.265 |
| Top Width (mm) | 6 |
| Angle. | 38 |
| Thickness (in) | 0.21 |
| Thickness (mm) | 5 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.1 |
7384
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 38.5 |
| Effective Length (mm) | 978 |
| Notched | false |
| Outside Circumference (in) | 38.78 |
| Outside Circumference (mm) | 985 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 38 |
| Thickness (in) | 0.24 |
| Thickness (mm) | 6 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.14 |
7385
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 38.51 |
| Effective Length (mm) | 978 |
| Notched | true |
| Outside Circumference (in) | 39.34 |
| Outside Circumference (mm) | 999 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 650 |
| Weight (lbs.) | 0.19 |
7388
| Cross Section | HC25 |
|---|---|
| Effective Length (in) | 39 |
| Effective Length (mm) | 991 |
| Notched | false |
| Outside Circumference (in) | 39.17 |
| Outside Circumference (mm) | 995 |
| Strand | 1 |
| Top Width (in) | 0.265 |
| Top Width (mm) | 6 |
| Angle. | 38 |
| Thickness (in) | 0.21 |
| Thickness (mm) | 5 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.11 |
7390
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 39 |
| Effective Length (mm) | 991 |
| Notched | true |
| Outside Circumference (in) | 39.83 |
| Outside Circumference (mm) | 1011 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 650 |
| Weight (lbs.) | 0.2 |
7395
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 39.5 |
| Effective Length (mm) | 1003 |
| Notched | true |
| Outside Circumference (in) | 40.33 |
| Outside Circumference (mm) | 1024 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.2 |
7400
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 40 |
| Effective Length (mm) | 1016 |
| Notched | true |
| Outside Circumference (in) | 40.83 |
| Outside Circumference (mm) | 1037 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.21 |
7404
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 40.5 |
| Effective Length (mm) | 1029 |
| Notched | false |
| Outside Circumference (in) | 40.75 |
| Outside Circumference (mm) | 1035 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 38 |
| Thickness (in) | 0.24 |
| Thickness (mm) | 6 |
| Customer Pack | 20 |
| Weight (lbs.) | 0.16 |
7405
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 40.5 |
| Effective Length (mm) | 1029 |
| Notched | true |
| Outside Circumference (in) | 41.33 |
| Outside Circumference (mm) | 1049 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.21 |
7410
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 40.99 |
| Effective Length (mm) | 1041 |
| Notched | true |
| Outside Circumference (in) | 41.82 |
| Outside Circumference (mm) | 1062 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.21 |
7417
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 41.5 |
| Effective Length (mm) | 1054 |
| Notched | true |
| Outside Circumference (in) | 42.33 |
| Outside Circumference (mm) | 1075 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.22 |
7419
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 42 |
| Effective Length (mm) | 1067 |
| Notched | false |
| Outside Circumference (in) | 42.32 |
| Outside Circumference (mm) | 1075 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 38 |
| Thickness (in) | 0.24 |
| Thickness (mm) | 6 |
| Customer Pack | 125 |
| Weight (lbs.) | 0.17 |
7420
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 42 |
| Effective Length (mm) | 1067 |
| Notched | true |
| Outside Circumference (in) | 42.83 |
| Outside Circumference (mm) | 1087 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.22 |
7425
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 42.51 |
| Effective Length (mm) | 1080 |
| Notched | true |
| Outside Circumference (in) | 43.34 |
| Outside Circumference (mm) | 1101 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.22 |
7430
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 43 |
| Effective Length (mm) | 1092 |
| Notched | true |
| Outside Circumference (in) | 43.83 |
| Outside Circumference (mm) | 1113 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 20 |
| Weight (lbs.) | 0.22 |
7435
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 43.5 |
| Effective Length (mm) | 1105 |
| Notched | true |
| Outside Circumference (in) | 44.33 |
| Outside Circumference (mm) | 1126 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.22 |
7440
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 44 |
| Effective Length (mm) | 1118 |
| Notched | true |
| Outside Circumference (in) | 44.83 |
| Outside Circumference (mm) | 1138 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.22 |
7444
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 44.5 |
| Effective Length (mm) | 1130 |
| Notched | false |
| Outside Circumference (in) | 44.69 |
| Outside Circumference (mm) | 1135 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 38 |
| Thickness (in) | 0.24 |
| Thickness (mm) | 6 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.17 |
7445
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 44.5 |
| Effective Length (mm) | 1130 |
| Notched | true |
| Outside Circumference (in) | 45.33 |
| Outside Circumference (mm) | 1151 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.23 |
7447M
| Cross Section | HC38 |
|---|---|
| Effective Length (in) | 44.78 |
| Effective Length (mm) | 1137 |
| Notched | false |
| Outside Circumference (in) | 45.25 |
| Outside Circumference (mm) | 1149 |
| Strand | 1 |
| Top Width (in) | 0.406 |
| Top Width (mm) | 10 |
| Angle. | 37 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 25 |
| Weight (lbs.) | 0.38 |
7448
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 44.75 |
| Effective Length (mm) | 1137 |
| Notched | true |
| Outside Circumference (in) | 45.58 |
| Outside Circumference (mm) | 1158 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.23 |
7450
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 45 |
| Effective Length (mm) | 1143 |
| Notched | true |
| Outside Circumference (in) | 45.82 |
| Outside Circumference (mm) | 1164 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 500 |
| Weight (lbs.) | 0.23 |
7453
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 45.25 |
| Effective Length (mm) | 1149 |
| Notched | true |
| Outside Circumference (in) | 46.07 |
| Outside Circumference (mm) | 1170 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 100 |
| Weight (lbs.) | 0.23 |
7455
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 45.5 |
| Effective Length (mm) | 1156 |
| Notched | true |
| Outside Circumference (in) | 46.32 |
| Outside Circumference (mm) | 1176.5 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.23 |
7460
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 46 |
| Effective Length (mm) | 1168 |
| Notched | true |
| Outside Circumference (in) | 46.82 |
| Outside Circumference (mm) | 1189 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.24 |
7465
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 46.5 |
| Effective Length (mm) | 1181 |
| Notched | true |
| Outside Circumference (in) | 47.32 |
| Outside Circumference (mm) | 1202 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.24 |
7470
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 47 |
| Effective Length (mm) | 1194 |
| Notched | true |
| Outside Circumference (in) | 47.82 |
| Outside Circumference (mm) | 1215 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.24 |
7473
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 47.25 |
| Effective Length (mm) | 1200 |
| Notched | true |
| Outside Circumference (in) | 48.07 |
| Outside Circumference (mm) | 1221 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 98 |
| Weight (lbs.) | 0.24 |
7475
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 47.5 |
| Effective Length (mm) | 1207 |
| Notched | true |
| Outside Circumference (in) | 48.32 |
| Outside Circumference (mm) | 1227 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.24 |
7480
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 48 |
| Effective Length (mm) | 1219 |
| Notched | true |
| Outside Circumference (in) | 48.82 |
| Outside Circumference (mm) | 1240 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.24 |
7483
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 48.3 |
| Effective Length (mm) | 1227 |
| Notched | true |
| Outside Circumference (in) | 49.12 |
| Outside Circumference (mm) | 1247 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.25 |
7485
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 48.5 |
| Effective Length (mm) | 1232 |
| Notched | true |
| Outside Circumference (in) | 49.32 |
| Outside Circumference (mm) | 1253 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.25 |
7490
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 49 |
| Effective Length (mm) | 1245 |
| Notched | true |
| Outside Circumference (in) | 49.83 |
| Outside Circumference (mm) | 1266 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.26 |
7495
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 49.5 |
| Effective Length (mm) | 1257 |
| Notched | true |
| Outside Circumference (in) | 50.32 |
| Outside Circumference (mm) | 1278 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.25 |
7496
| Cross Section | HC31 |
|---|---|
| Effective Length (in) | 49.5 |
| Effective Length (mm) | 1257 |
| Notched | false |
| Outside Circumference (in) | 49.61 |
| Outside Circumference (mm) | 1260 |
| Strand | 1 |
| Top Width (in) | 0.325 |
| Top Width (mm) | 8 |
| Angle. | 38 |
| Thickness (in) | 0.24 |
| Thickness (mm) | 6 |
| Customer Pack | 125 |
| Weight (lbs.) | 0.19 |
7500
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 49.99 |
| Effective Length (mm) | 1270 |
| Notched | true |
| Outside Circumference (in) | 50.81 |
| Outside Circumference (mm) | 1290 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.26 |
7508
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 50.49 |
| Effective Length (mm) | 1282 |
| Notched | true |
| Outside Circumference (in) | 51.31 |
| Outside Circumference (mm) | 1303 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.24 |
7512
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 51 |
| Effective Length (mm) | 1295 |
| Notched | true |
| Outside Circumference (in) | 51.82 |
| Outside Circumference (mm) | 1316 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.25 |
7516
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 51.5 |
| Effective Length (mm) | 1308 |
| Notched | true |
| Outside Circumference (in) | 52.32 |
| Outside Circumference (mm) | 1329 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.25 |
7520
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 52 |
| Effective Length (mm) | 1321 |
| Notched | true |
| Outside Circumference (in) | 52.82 |
| Outside Circumference (mm) | 1342 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.25 |
7525
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 52.5 |
| Effective Length (mm) | 1334 |
| Notched | true |
| Outside Circumference (in) | 53.32 |
| Outside Circumference (mm) | 1354 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.25 |
7530
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 53 |
| Effective Length (mm) | 1346 |
| Notched | true |
| Outside Circumference (in) | 53.82 |
| Outside Circumference (mm) | 1367 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.27 |
7535
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 53.51 |
| Effective Length (mm) | 1359 |
| Notched | true |
| Outside Circumference (in) | 54.33 |
| Outside Circumference (mm) | 1380 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.28 |
7541
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 54 |
| Effective Length (mm) | 1372 |
| Notched | true |
| Outside Circumference (in) | 54.82 |
| Outside Circumference (mm) | 1392 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.28 |
7545
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 54.5 |
| Effective Length (mm) | 1384 |
| Notched | true |
| Outside Circumference (in) | 55.32 |
| Outside Circumference (mm) | 1405 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.26 |
7550
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 55 |
| Effective Length (mm) | 1397 |
| Notched | true |
| Outside Circumference (in) | 55.82 |
| Outside Circumference (mm) | 1418 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.28 |
7555
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 55.5 |
| Effective Length (mm) | 1410 |
| Notched | true |
| Outside Circumference (in) | 56.31 |
| Outside Circumference (mm) | 1430 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.29 |
7560
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 56 |
| Effective Length (mm) | 1422 |
| Notched | true |
| Outside Circumference (in) | 56.81 |
| Outside Circumference (mm) | 1443 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.27 |
7565
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 56.5 |
| Effective Length (mm) | 1435 |
| Notched | true |
| Outside Circumference (in) | 57.31 |
| Outside Circumference (mm) | 1456 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.27 |
7570
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 57 |
| Effective Length (mm) | 1448 |
| Notched | true |
| Outside Circumference (in) | 57.81 |
| Outside Circumference (mm) | 1468 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.29 |
7575
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 57.5 |
| Effective Length (mm) | 1461 |
| Notched | true |
| Outside Circumference (in) | 58.31 |
| Outside Circumference (mm) | 1481 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.27 |
7580
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 58 |
| Effective Length (mm) | 1473 |
| Notched | true |
| Outside Circumference (in) | 58.81 |
| Outside Circumference (mm) | 1494 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.28 |
7585
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 58.5 |
| Effective Length (mm) | 1486 |
| Notched | true |
| Outside Circumference (in) | 59.31 |
| Outside Circumference (mm) | 1506 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.3 |
7590
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 59 |
| Effective Length (mm) | 1499 |
| Notched | true |
| Outside Circumference (in) | 59.81 |
| Outside Circumference (mm) | 1519 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.28 |
7597
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 59.5 |
| Effective Length (mm) | 1511 |
| Notched | true |
| Outside Circumference (in) | 60.31 |
| Outside Circumference (mm) | 1532 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 375 |
| Weight (lbs.) | 0.28 |
7603
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 60 |
| Effective Length (mm) | 1524 |
| Notched | true |
| Outside Circumference (in) | 60.81 |
| Outside Circumference (mm) | 1544.5 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 375 |
| Weight (lbs.) | 0.31 |
7612
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 61 |
| Effective Length (mm) | 1549 |
| Notched | true |
| Outside Circumference (in) | 61.81 |
| Outside Circumference (mm) | 1570 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 375 |
| Weight (lbs.) | 0.32 |
7619
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 62 |
| Effective Length (mm) | 1575 |
| Notched | true |
| Outside Circumference (in) | 62.81 |
| Outside Circumference (mm) | 1595 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 125 |
| Weight (lbs.) | 0.29 |
7625
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 62.5 |
| Effective Length (mm) | 1588 |
| Notched | true |
| Outside Circumference (in) | 63.31 |
| Outside Circumference (mm) | 1608 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.32 |
7630
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 63 |
| Effective Length (mm) | 1600 |
| Notched | true |
| Outside Circumference (in) | 63.31 |
| Outside Circumference (mm) | 1608 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.32 |
7640
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 64 |
| Effective Length (mm) | 1626 |
| Notched | true |
| Outside Circumference (in) | 64.81 |
| Outside Circumference (mm) | 1646 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 375 |
| Weight (lbs.) | 0.3 |
7650
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 65 |
| Effective Length (mm) | 1651 |
| Notched | true |
| Outside Circumference (in) | 65.8 |
| Outside Circumference (mm) | 1671 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.33 |
7660
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 66 |
| Effective Length (mm) | 1676 |
| Notched | true |
| Outside Circumference (in) | 66.8 |
| Outside Circumference (mm) | 1697 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.34 |
7665
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 66.5 |
| Effective Length (mm) | 1689 |
| Notched | true |
| Outside Circumference (in) | 67.3 |
| Outside Circumference (mm) | 1709 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.34 |
7673
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 67 |
| Effective Length (mm) | 1702 |
| Notched | true |
| Outside Circumference (in) | 67.8 |
| Outside Circumference (mm) | 1722 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.34 |
7680
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 68 |
| Effective Length (mm) | 1727 |
| Notched | true |
| Outside Circumference (in) | 68.8 |
| Outside Circumference (mm) | 1747.5 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.35 |
7695
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 69.5 |
| Effective Length (mm) | 1765 |
| Notched | true |
| Outside Circumference (in) | 70.3 |
| Outside Circumference (mm) | 1785 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.31 |
7730
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 73 |
| Effective Length (mm) | 1854 |
| Notched | true |
| Outside Circumference (in) | 73.79 |
| Outside Circumference (mm) | 1874 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.35 |
7760
| Cross Section | HC41 |
|---|---|
| Effective Length (in) | 75.99 |
| Effective Length (mm) | 1930 |
| Notched | true |
| Outside Circumference (in) | 76.78 |
| Outside Circumference (mm) | 1950 |
| Strand | 1 |
| Top Width (in) | 0.41 |
| Top Width (mm) | 10 |
| Angle. | 36 |
| Thickness (in) | 0.33 |
| Thickness (mm) | 8 |
| Customer Pack | 75 |
| Weight (lbs.) | 0.4 |
9245
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 24.5 |
| Effective Length (mm) | 622 |
| Notched | true |
| Outside Circumference (in) | 25.14 |
| Outside Circumference (mm) | 638.5 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 800 |
| Weight (lbs.) | 0.17 |
9255
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 25.5 |
| Effective Length (mm) | 648 |
| Notched | true |
| Outside Circumference (in) | 26.13 |
| Outside Circumference (mm) | 664 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 800 |
| Weight (lbs.) | 0.18 |
9260
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 26 |
| Effective Length (mm) | 660 |
| Notched | true |
| Outside Circumference (in) | 26.63 |
| Outside Circumference (mm) | 676 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 20 |
| Weight (lbs.) | 0.19 |
9265
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 26.5 |
| Effective Length (mm) | 673 |
| Notched | true |
| Outside Circumference (in) | 27.13 |
| Outside Circumference (mm) | 689 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.19 |
9270
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 27 |
| Effective Length (mm) | 686 |
| Notched | true |
| Outside Circumference (in) | 27.63 |
| Outside Circumference (mm) | 702 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.19 |
9279
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 27.89 |
| Effective Length (mm) | 708 |
| Notched | true |
| Outside Circumference (in) | 28.52 |
| Outside Circumference (mm) | 724 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 700 |
| Weight (lbs.) | 0.2 |
9290
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 29 |
| Effective Length (mm) | 737 |
| Notched | true |
| Outside Circumference (in) | 29.63 |
| Outside Circumference (mm) | 753 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 700 |
| Weight (lbs.) | 0.2 |
9295
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 29.5 |
| Effective Length (mm) | 749 |
| Notched | true |
| Outside Circumference (in) | 30.13 |
| Outside Circumference (mm) | 765 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 700 |
| Weight (lbs.) | 0.21 |
9300
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 30 |
| Effective Length (mm) | 762 |
| Notched | true |
| Outside Circumference (in) | 30.63 |
| Outside Circumference (mm) | 778 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 150 |
| Weight (lbs.) | 0.21 |
9305
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 30.5 |
| Effective Length (mm) | 775 |
| Notched | true |
| Outside Circumference (in) | 31.13 |
| Outside Circumference (mm) | 791 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 600 |
| Weight (lbs.) | 0.21 |
9309
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 31 |
| Effective Length (mm) | 787 |
| Notched | true |
| Outside Circumference (in) | 31.63 |
| Outside Circumference (mm) | 803 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 600 |
| Weight (lbs.) | 0.22 |
9313
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 31.48 |
| Effective Length (mm) | 800 |
| Notched | true |
| Outside Circumference (in) | 32.11 |
| Outside Circumference (mm) | 815.5 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 600 |
| Weight (lbs.) | 0.22 |
9319
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 32 |
| Effective Length (mm) | 813 |
| Notched | true |
| Outside Circumference (in) | 32.63 |
| Outside Circumference (mm) | 829 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 600 |
| Weight (lbs.) | 0.22 |
9325
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 32.5 |
| Effective Length (mm) | 826 |
| Notched | true |
| Outside Circumference (in) | 33.13 |
| Outside Circumference (mm) | 841.5 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 600 |
| Weight (lbs.) | 0.22 |
9330
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 33 |
| Effective Length (mm) | 838 |
| Notched | true |
| Outside Circumference (in) | 33.63 |
| Outside Circumference (mm) | 854 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 600 |
| Weight (lbs.) | 0.24 |
9335
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 33.5 |
| Effective Length (mm) | 851 |
| Notched | true |
| Outside Circumference (in) | 34.13 |
| Outside Circumference (mm) | 867 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 600 |
| Weight (lbs.) | 0.24 |
9345
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 34.5 |
| Effective Length (mm) | 876 |
| Notched | true |
| Outside Circumference (in) | 35.13 |
| Outside Circumference (mm) | 892 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 550 |
| Weight (lbs.) | 0.24 |
9348M
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 34.84 |
| Effective Length (mm) | 885 |
| Notched | true |
| Outside Circumference (in) | 35.25 |
| Outside Circumference (mm) | 895 |
| Strand | 1 |
| Top Width (in) | 0.531 |
| Top Width (mm) | 13 |
| Angle. | 30 |
| Thickness (in) | 0.37 |
| Thickness (mm) | 9 |
| Customer Pack | 76 |
| Weight (lbs.) | 0.22 |
9350
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 35 |
| Effective Length (mm) | 889 |
| Notched | true |
| Outside Circumference (in) | 35.62 |
| Outside Circumference (mm) | 905 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 550 |
| Weight (lbs.) | 0.25 |
9355
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 35.5 |
| Effective Length (mm) | 902 |
| Notched | true |
| Outside Circumference (in) | 36.12 |
| Outside Circumference (mm) | 917 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 550 |
| Weight (lbs.) | 0.24 |
9360
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 36 |
| Effective Length (mm) | 914 |
| Notched | true |
| Outside Circumference (in) | 36.62 |
| Outside Circumference (mm) | 930 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 550 |
| Weight (lbs.) | 0.25 |
9362M
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 36.23 |
| Effective Length (mm) | 920 |
| Notched | true |
| Outside Circumference (in) | 36.625 |
| Outside Circumference (mm) | 930 |
| Strand | 1 |
| Top Width (in) | 0.531 |
| Top Width (mm) | 13 |
| Angle. | 30 |
| Thickness (in) | 0.37 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.2 |
9365
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 36.5 |
| Effective Length (mm) | 927 |
| Notched | true |
| Outside Circumference (in) | 36.88 |
| Outside Circumference (mm) | 937 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 550 |
| Weight (lbs.) | 0.26 |
9370
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 36.98 |
| Effective Length (mm) | 939 |
| Notched | true |
| Outside Circumference (in) | 37.6 |
| Outside Circumference (mm) | 955 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 550 |
| Weight (lbs.) | 0.26 |
9375
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 37.5 |
| Effective Length (mm) | 953 |
| Notched | true |
| Outside Circumference (in) | 38.12 |
| Outside Circumference (mm) | 968 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.26 |
9378
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 37.73 |
| Effective Length (mm) | 958 |
| Notched | true |
| Outside Circumference (in) | 38.35 |
| Outside Circumference (mm) | 974 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 125 |
| Weight (lbs.) | 0.26 |
9380
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 38 |
| Effective Length (mm) | 965 |
| Notched | true |
| Outside Circumference (in) | 38.62 |
| Outside Circumference (mm) | 981 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.27 |
9385
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 38.5 |
| Effective Length (mm) | 978 |
| Notched | true |
| Outside Circumference (in) | 39.12 |
| Outside Circumference (mm) | 994 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.27 |
9390
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 38.99 |
| Effective Length (mm) | 990 |
| Notched | true |
| Outside Circumference (in) | 39.61 |
| Outside Circumference (mm) | 1006 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.28 |
9395
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 39.5 |
| Effective Length (mm) | 1003 |
| Notched | true |
| Outside Circumference (in) | 40.12 |
| Outside Circumference (mm) | 1019 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.28 |
9400
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 40 |
| Effective Length (mm) | 1016 |
| Notched | true |
| Outside Circumference (in) | 40.62 |
| Outside Circumference (mm) | 1031 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.28 |
9403
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 40.25 |
| Effective Length (mm) | 1022 |
| Notched | true |
| Outside Circumference (in) | 40.87 |
| Outside Circumference (mm) | 1038 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 100 |
| Weight (lbs.) | 0.28 |
9405
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 40.5 |
| Effective Length (mm) | 1029 |
| Notched | true |
| Outside Circumference (in) | 41.12 |
| Outside Circumference (mm) | 1044 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.28 |
9412
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 41 |
| Effective Length (mm) | 1041 |
| Notched | true |
| Outside Circumference (in) | 41.62 |
| Outside Circumference (mm) | 1057 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.29 |
9415
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 41.5 |
| Effective Length (mm) | 1054 |
| Notched | true |
| Outside Circumference (in) | 42.12 |
| Outside Circumference (mm) | 1070 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.29 |
9420
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 42 |
| Effective Length (mm) | 1067 |
| Notched | true |
| Outside Circumference (in) | 42.62 |
| Outside Circumference (mm) | 1082 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 450 |
| Weight (lbs.) | 0.29 |
9425
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 42.5 |
| Effective Length (mm) | 1080 |
| Notched | true |
| Outside Circumference (in) | 43.12 |
| Outside Circumference (mm) | 1095 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.3 |
9430
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 43 |
| Effective Length (mm) | 1092 |
| Notched | true |
| Outside Circumference (in) | 43.62 |
| Outside Circumference (mm) | 1108 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.3 |
9435
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 43.5 |
| Effective Length (mm) | 1105 |
| Notched | true |
| Outside Circumference (in) | 44.12 |
| Outside Circumference (mm) | 1120 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.3 |
9440
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 44 |
| Effective Length (mm) | 1118 |
| Notched | true |
| Outside Circumference (in) | 44.62 |
| Outside Circumference (mm) | 1133 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.31 |
9447
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 44.5 |
| Effective Length (mm) | 1130 |
| Notched | true |
| Outside Circumference (in) | 45.12 |
| Outside Circumference (mm) | 1146 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.31 |
9451
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 45 |
| Effective Length (mm) | 1143 |
| Notched | true |
| Outside Circumference (in) | 45.62 |
| Outside Circumference (mm) | 1159 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.35 |
9452M
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 45.22 |
| Effective Length (mm) | 1149 |
| Notched | true |
| Outside Circumference (in) | 45.625 |
| Outside Circumference (mm) | 1158 |
| Strand | 1 |
| Top Width (in) | 0.531 |
| Top Width (mm) | 13 |
| Angle. | 30 |
| Thickness (in) | 0.37 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.3 |
9453M
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 45.34 |
| Effective Length (mm) | 1152 |
| Notched | true |
| Outside Circumference (in) | 45.75 |
| Outside Circumference (mm) | 1161 |
| Strand | 1 |
| Top Width (in) | 0.531 |
| Top Width (mm) | 13 |
| Angle. | 30 |
| Thickness (in) | 0.37 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.4 |
9455
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 45.5 |
| Effective Length (mm) | 1156 |
| Notched | true |
| Outside Circumference (in) | 46.11 |
| Outside Circumference (mm) | 1171 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.32 |
9463
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 46 |
| Effective Length (mm) | 1168 |
| Notched | true |
| Outside Circumference (in) | 46.61 |
| Outside Circumference (mm) | 1184 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.33 |
9465
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 46.5 |
| Effective Length (mm) | 1181 |
| Notched | true |
| Outside Circumference (in) | 47.11 |
| Outside Circumference (mm) | 1196.5 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.32 |
9470
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 47 |
| Effective Length (mm) | 1194 |
| Notched | true |
| Outside Circumference (in) | 47.61 |
| Outside Circumference (mm) | 1209 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.33 |
9476
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 47.5 |
| Effective Length (mm) | 1207 |
| Notched | true |
| Outside Circumference (in) | 48.11 |
| Outside Circumference (mm) | 1222 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.33 |
9480
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 48 |
| Effective Length (mm) | 1219 |
| Notched | true |
| Outside Circumference (in) | 48.61 |
| Outside Circumference (mm) | 1235 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.34 |
9485
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 48.5 |
| Effective Length (mm) | 1232 |
| Notched | true |
| Outside Circumference (in) | 49.11 |
| Outside Circumference (mm) | 1247 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.34 |
9490
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 49 |
| Effective Length (mm) | 1245 |
| Notched | true |
| Outside Circumference (in) | 49.61 |
| Outside Circumference (mm) | 1260 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.35 |
9492M
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 49.21 |
| Effective Length (mm) | 1250 |
| Notched | true |
| Outside Circumference (in) | 49.625 |
| Outside Circumference (mm) | 1259 |
| Strand | 1 |
| Top Width (in) | 0.579 |
| Top Width (mm) | 15 |
| Angle. | 40 |
| Thickness (in) | 0.37 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.25 |
9495
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 49.5 |
| Effective Length (mm) | 1257 |
| Notched | true |
| Outside Circumference (in) | 50.11 |
| Outside Circumference (mm) | 1273 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.34 |
9500
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 50 |
| Effective Length (mm) | 1270 |
| Notched | true |
| Outside Circumference (in) | 50.61 |
| Outside Circumference (mm) | 1285.5 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.35 |
9505
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 50.5 |
| Effective Length (mm) | 1283 |
| Notched | true |
| Outside Circumference (in) | 51.11 |
| Outside Circumference (mm) | 1298 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 400 |
| Weight (lbs.) | 0.35 |
9510
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 51 |
| Effective Length (mm) | 1295 |
| Notched | true |
| Outside Circumference (in) | 51.61 |
| Outside Circumference (mm) | 1311 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 350 |
| Weight (lbs.) | 0.36 |
9520
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 52 |
| Effective Length (mm) | 1321 |
| Notched | true |
| Outside Circumference (in) | 52.61 |
| Outside Circumference (mm) | 1336 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 350 |
| Weight (lbs.) | 0.36 |
9525
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 52.5 |
| Effective Length (mm) | 1334 |
| Notched | true |
| Outside Circumference (in) | 53.11 |
| Outside Circumference (mm) | 1349 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 350 |
| Weight (lbs.) | 0.35 |
9530
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 53 |
| Effective Length (mm) | 1346 |
| Notched | true |
| Outside Circumference (in) | 53.61 |
| Outside Circumference (mm) | 1362 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 270 |
| Weight (lbs.) | 0.37 |
9540
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 54 |
| Effective Length (mm) | 1372 |
| Notched | true |
| Outside Circumference (in) | 54.61 |
| Outside Circumference (mm) | 1387 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 350 |
| Weight (lbs.) | 0.37 |
9545
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 54.5 |
| Effective Length (mm) | 1384 |
| Notched | true |
| Outside Circumference (in) | 55.11 |
| Outside Circumference (mm) | 1399 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.37 |
9550
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 55 |
| Effective Length (mm) | 1397 |
| Notched | true |
| Outside Circumference (in) | 55.61 |
| Outside Circumference (mm) | 1412 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 350 |
| Weight (lbs.) | 0.39 |
9551M
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 55.18 |
| Effective Length (mm) | 1402 |
| Notched | true |
| Outside Circumference (in) | 55.5 |
| Outside Circumference (mm) | 1411 |
| Strand | 1 |
| Top Width (in) | 0.531 |
| Top Width (mm) | 13 |
| Angle. | 40 |
| Thickness (in) | 0.37 |
| Thickness (mm) | 9 |
| Customer Pack | 350 |
| Weight (lbs.) | 0.35 |
9560
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 56 |
| Effective Length (mm) | 1422 |
| Notched | true |
| Outside Circumference (in) | 56.61 |
| Outside Circumference (mm) | 1438 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.38 |
9565
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 56.5 |
| Effective Length (mm) | 1435 |
| Notched | true |
| Outside Circumference (in) | 57.1 |
| Outside Circumference (mm) | 1450 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.38 |
9570
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 57 |
| Effective Length (mm) | 1448 |
| Notched | true |
| Outside Circumference (in) | 57.6 |
| Outside Circumference (mm) | 1463 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.4 |
9585
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 58.5 |
| Effective Length (mm) | 1486 |
| Notched | true |
| Outside Circumference (in) | 59.1 |
| Outside Circumference (mm) | 1501 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.36 |
9590
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 59 |
| Effective Length (mm) | 1499 |
| Notched | true |
| Outside Circumference (in) | 59.6 |
| Outside Circumference (mm) | 1539 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.4 |
9600
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 60 |
| Effective Length (mm) | 1524 |
| Notched | true |
| Outside Circumference (in) | 60.6 |
| Outside Circumference (mm) | 1539 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.42 |
9605
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 60.5 |
| Effective Length (mm) | 1537 |
| Notched | true |
| Outside Circumference (in) | 61.1 |
| Outside Circumference (mm) | 1552 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.41 |
9610
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 61 |
| Effective Length (mm) | 1549 |
| Notched | true |
| Outside Circumference (in) | 61.6 |
| Outside Circumference (mm) | 1552 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.41 |
9620
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 62 |
| Effective Length (mm) | 1575 |
| Notched | true |
| Outside Circumference (in) | 62.6 |
| Outside Circumference (mm) | 1590 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.42 |
9625
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 62.5 |
| Effective Length (mm) | 1588 |
| Notched | true |
| Outside Circumference (in) | 63.1 |
| Outside Circumference (mm) | 1603 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.42 |
9630
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 63 |
| Effective Length (mm) | 1600 |
| Notched | true |
| Outside Circumference (in) | 63.6 |
| Outside Circumference (mm) | 1615 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.42 |
9635
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 63.5 |
| Effective Length (mm) | 1613 |
| Notched | true |
| Outside Circumference (in) | 64.1 |
| Outside Circumference (mm) | 1628 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.43 |
9640
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 64.01 |
| Effective Length (mm) | 1626 |
| Notched | true |
| Outside Circumference (in) | 64.61 |
| Outside Circumference (mm) | 1641 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.44 |
9650
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 65.01 |
| Effective Length (mm) | 1651 |
| Notched | true |
| Outside Circumference (in) | 65.6 |
| Outside Circumference (mm) | 1666 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.44 |
9660
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 66 |
| Effective Length (mm) | 1676 |
| Notched | true |
| Outside Circumference (in) | 66.59 |
| Outside Circumference (mm) | 1691 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.44 |
9670
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 67 |
| Effective Length (mm) | 1702 |
| Notched | true |
| Outside Circumference (in) | 67.59 |
| Outside Circumference (mm) | 1716 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.45 |
9680
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 68 |
| Effective Length (mm) | 1727 |
| Notched | true |
| Outside Circumference (in) | 68.59 |
| Outside Circumference (mm) | 1742 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.45 |
9690
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 69 |
| Effective Length (mm) | 1753 |
| Notched | true |
| Outside Circumference (in) | 69.59 |
| Outside Circumference (mm) | 1767 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 300 |
| Weight (lbs.) | 0.47 |
9700
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 70 |
| Effective Length (mm) | 1778 |
| Notched | true |
| Outside Circumference (in) | 70.59 |
| Outside Circumference (mm) | 1793 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.47 |
9710
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 71 |
| Effective Length (mm) | 1803 |
| Notched | true |
| Outside Circumference (in) | 71.59 |
| Outside Circumference (mm) | 1818 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.48 |
9720
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 72 |
| Effective Length (mm) | 1829 |
| Notched | true |
| Outside Circumference (in) | 72.59 |
| Outside Circumference (mm) | 1844 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.48 |
9730
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 73 |
| Effective Length (mm) | 1854 |
| Notched | true |
| Outside Circumference (in) | 73.59 |
| Outside Circumference (mm) | 1869 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.49 |
9740
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 74 |
| Effective Length (mm) | 1880 |
| Notched | true |
| Outside Circumference (in) | 74.59 |
| Outside Circumference (mm) | 1894.5 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.5 |
9745
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 74.49 |
| Effective Length (mm) | 1892 |
| Notched | true |
| Outside Circumference (in) | 75.08 |
| Outside Circumference (mm) | 1907 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 65 |
| Weight (lbs.) | 0.5 |
9755
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 75.5 |
| Effective Length (mm) | 1918 |
| Notched | true |
| Outside Circumference (in) | 76.14 |
| Outside Circumference (mm) | 1934 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 250 |
| Weight (lbs.) | 0.51 |
9765
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 76.5 |
| Effective Length (mm) | 1943 |
| Notched | true |
| Outside Circumference (in) | 77.08 |
| Outside Circumference (mm) | 1958 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 65 |
| Weight (lbs.) | 0.51 |
9770
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 77 |
| Effective Length (mm) | 1956 |
| Notched | true |
| Outside Circumference (in) | 77.58 |
| Outside Circumference (mm) | 1970.5 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 65 |
| Weight (lbs.) | 0.52 |
9775
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 77.5 |
| Effective Length (mm) | 1969 |
| Notched | true |
| Outside Circumference (in) | 78.08 |
| Outside Circumference (mm) | 1983 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 70 |
| Weight (lbs.) | 0.53 |
9810
| Cross Section | HC50 |
|---|---|
| Effective Length (in) | 81 |
| Effective Length (mm) | 2057 |
| Notched | true |
| Outside Circumference (in) | 81.58 |
| Outside Circumference (mm) | 2072 |
| Strand | 1 |
| Top Width (in) | 0.47 |
| Top Width (mm) | 12 |
| Angle. | 36 |
| Thickness (in) | 0.36 |
| Thickness (mm) | 9 |
| Customer Pack | 60 |
| Weight (lbs.) | 0.55 |
870174834
No variation attributes.
87010013
No variation attributes.
870194254
No variation attributes.
87010015
No variation attributes.
870194054
No variation attributes.
870175004
No variation attributes.
87010014
No variation attributes.
870175904
No variation attributes.
87010012
No variation attributes.
Specifications
| Cross Section | HC41, HC31, HC25, HC38, HC50 |
|---|---|
| Effective Length (in) | 20.69 – 81 |
| Effective Length (mm) | 526 – 2057 |
| Notched | true, false |
| Outside Circumference (in) | 21.54 – 81.58 |
| Outside Circumference (mm) | 547 – 2072 |
| Strand | 1 |
| Top Width (in) | 0.265 – 0.579 |
| Top Width (mm) | 6 – 15 |
| Angle. | 30 – 40 |
| Thickness (in) | 0.21 – 0.37 |
| Thickness (mm) | 5 – 9 |
| Customer Pack | 20 – 850 |
| Weight (lbs.) | 0.07 – 0.55 |
PDF Documents
No PDF documents.
