Attributes
| Part Number | 7252-000000-000000 |
|---|
Description
Live Swivel Gates Live Swivels have a robust design that outperforms the competition. Increase productivity and reduce operating costs. Robust design with free-floating, self-lubricating thrust washer has replacement factor of up to 10X traditional swivels. Solution for applications where hydraulic hoses are subject to twist.
Variations (54)
12BSPP-12BSPP-LX / G93345-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Hex Body (in) | 1.63 |
| Hex Shank (in) | 0.94 |
| Overall Length (in) | 4.52 |
| L Length (in) | 4.52 |
| L Length (mm) | 114.8 |
| Inside Diameter (mm) | 50.8 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.87 |
12JIC SWIVEL SEAL KIT / G93500-0012
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.031 |
12MB-12FJ/FB-LX90S / G93460-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 3.54 |
12MB-12MJ-LX90S / G93530-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 3.79 |
12MFFOR-12FFORX-LX / G93724-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Hex Body (in) | 1.75 |
| Hex Shank (in) | 1.06 |
| Overall Length (in) | 3.86 |
| L Length (in) | 3.86 |
| L Length (mm) | 98 |
| Inside Diameter (mm) | 53.1 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2.09 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.06 |
12MFFOR-12MFFOR-LX / G93742-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Hex Body (in) | 1.75 |
| Hex Shank (in) | 1.06 |
| Overall Length (in) | 4.52 |
| L Length (in) | 4.52 |
| L Length (mm) | 114.8 |
| Inside Diameter (mm) | 53.1 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2.09 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.28 |
12MJ-12FB-LX90 / G93455-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.37 |
12MJ-12FJ/FB-LX / G93450-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Hex Body (in) | 1.63 |
| Hex Shank (in) | 0.94 |
| Overall Length (in) | 4.12 |
| L Length (in) | 4.12 |
| L Length (mm) | 104.6 |
| Inside Diameter (mm) | 50.8 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.0 |
12MJ-12FP-LX / G93510-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Hex Body (in) | 1.63 |
| Hex Shank (in) | 0.94 |
| Overall Length (in) | 4.19 |
| L Length (in) | 4.19 |
| L Length (mm) | 106.4 |
| Inside Diameter (mm) | 50.8 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.0 |
12MJ-12MJ-LX / G93410-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Hex Body (in) | 1.63 |
| Hex Shank (in) | 0.94 |
| Overall Length (in) | 4.94 |
| L Length (in) | 4.94 |
| L Length (mm) | 125.5 |
| Inside Diameter (mm) | 50.8 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.92 |
12MJ-12MJ-LX90 / G93415-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.72 |
12MJ-12MJ-LX90S / G93420-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 3.79 |
12MP-12FP-LX90 / G93340-1212
| End 2 Diameter (mm) | 12 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 12 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.35 |
12ORS LIVE SWIVEL SEAL KIT / G93600-0012
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.032 |
16BSPP-16BSPP-LX / G93345-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Hex Body (in) | 1.88 |
| Hex Shank (in) | 1.19 |
| Overall Length (in) | 5.06 |
| L Length (in) | 5.06 |
| L Length (mm) | 128.5 |
| Inside Diameter (mm) | 56.4 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2.22 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.62 |
16JIC SWIVEL SEAL KIT / G93500-0016
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.036 |
16MB-16FJ/FB-LX90S / G93460-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 4.73 |
16MB-16FP-LX90S / G93520-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 4.73 |
16MB-16MJ-LX90S / G93530-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 5.21 |
16MFFOR-16FFORX-LX / G93724-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Hex Body (in) | 2 |
| Hex Shank (in) | 1.31 |
| Overall Length (in) | 4.38 |
| L Length (in) | 4.38 |
| L Length (mm) | 111.3 |
| Inside Diameter (mm) | 58.7 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2.31 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.8 |
16MFFOR-16MFFOR-LX / G93742-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Hex Body (in) | 2 |
| Hex Shank (in) | 1.31 |
| Overall Length (in) | 5.12 |
| L Length (in) | 5.12 |
| L Length (mm) | 130 |
| Inside Diameter (mm) | 58.7 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2.31 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 3.15 |
16MJ-16FB-LX90 / G93455-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 3.29 |
16MJ-16FJ/FB-LX / G93450-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Hex Body (in) | 1.88 |
| Hex Shank (in) | 1.88 |
| Overall Length (in) | 4.63 |
| L Length (in) | 4.63 |
| L Length (mm) | 117.6 |
| Inside Diameter (mm) | 56.4 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2.22 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.84 |
16MJ-16FP-LX / G93510-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Hex Body (in) | 1.88 |
| Hex Shank (in) | 1.88 |
| Overall Length (in) | 4.88 |
| L Length (in) | 4.88 |
| L Length (mm) | 124 |
| Inside Diameter (mm) | 56.4 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2.22 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.7 |
16MJ-16MJ-LX / G93410-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Hex Body (in) | 1.88 |
| Hex Shank (in) | 1.19 |
| Overall Length (in) | 5.56 |
| L Length (in) | 5.56 |
| L Length (mm) | 141.2 |
| Inside Diameter (mm) | 56.4 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 2.22 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.84 |
16MJ-16MJ-LX90 / G93415-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 3.71 |
16MJ-16MJ-LX90S / G93420-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 5.21 |
16MP-16FP-LX90 / G93340-1616
| End 2 Diameter (mm) | 16 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 16 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 3.22 |
16ORS LIVE SWIVEL SEAL KIT / G93600-0016
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.037 |
20JIC SWIVEL SEAL KIT / G93500-0020
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.039 |
20MJ-20FB-LX90 / G93455-2020
| End 2 Diameter (mm) | 20 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 20 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 5.71 |
20MJ-20FJ/FB-LX / G93450-2020
| End 2 Diameter (mm) | 20 |
|---|---|
| Hex Body (in) | 2.38 |
| Hex Shank (in) | 1.5 |
| Overall Length (in) | 5.12 |
| L Length (in) | 5.12 |
| L Length (mm) | 130 |
| Inside Diameter (mm) | 69.9 |
| Max. Working Pressure | 5500 |
| Max. Working Pressure (Bar) | 379.2 |
| Diameter (in) | 2.75 |
| End 1 Diameter (mm) | 20 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 4.57 |
20MJ-20MJ-LX90 / G93415-2020
| End 2 Diameter (mm) | 20 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 20 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 6.4 |
24JIC SWIVEL SEAL KIT / G93500-0024
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.044 |
32MJ-32MJ-LX / G93410-3232
| End 2 Diameter (mm) | 32 |
|---|---|
| Hex Body (in) | 3.25 |
| Hex Shank (in) | 2.31 |
| Overall Length (in) | 7.69 |
| L Length (in) | 7.69 |
| L Length (mm) | 195.3 |
| Inside Diameter (mm) | 98.6 |
| Max. Working Pressure | 3000 |
| Max. Working Pressure (Bar) | 206.8 |
| Diameter (in) | 3.88 |
| End 1 Diameter (mm) | 32 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 9.91 |
6JIC SWIVEL SEAL KIT / G93500-0006
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.02 |
6MB-6FJ/FB-LX90S / G93460-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.0 |
6MB-6MJ-LX90S / G93530-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.07 |
6MJ-6MJ-LX / G93410-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| Hex Body (in) | 1 |
| Hex Shank (in) | 0.5 |
| Overall Length (in) | 2.91 |
| L Length (in) | 2.91 |
| L Length (mm) | 73.9 |
| Inside Diameter (mm) | 31.8 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 1.25 |
| End 1 Diameter (mm) | 6 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.47 |
6MJ-6MJ-LX90S / G93420-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.07 |
6MP-6FP-LX90 / G93340-0606
| End 2 Diameter (mm) | 6 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 6 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.66 |
8BSPP-8BSPP-LX / G93345-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Hex Body (in) | 1.31 |
| Hex Shank (in) | 0.75 |
| Overall Length (in) | 3.44 |
| L Length (in) | 3.44 |
| L Length (mm) | 87.4 |
| Inside Diameter (mm) | 38.9 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 1.53 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.9 |
8JIC SWIVEL SEAL KIT / G93500-0008
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.021 |
8MB-8FJ/FB-LX90S / G93460-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.99 |
8MB-8MJ-LX90S / G93530-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.07 |
8MFFOR-8MFFOR-LX / G93742-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Hex Body (in) | 0.94 |
| Hex Shank (in) | 0.75 |
| Overall Length (in) | 3.50 |
| L Length (in) | 3.5 |
| L Length (mm) | 88.9 |
| Inside Diameter (mm) | 38.9 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 1.53 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.9 |
8MJ-8FB-LX90 / G93455-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.04 |
8MJ-8FJ/FB-LX / G93450-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Hex Body (in) | 1.25 |
| Hex Shank (in) | 0.69 |
| Overall Length (in) | 3.31 |
| L Length (in) | 3.31 |
| L Length (mm) | 84.1 |
| Inside Diameter (mm) | 38.1 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 1.50 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.9 |
8MJ-8FP-LX / G93510-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Hex Body (in) | 1.25 |
| Hex Shank (in) | 0.69 |
| Overall Length (in) | 3.31 |
| L Length (in) | 3.31 |
| L Length (mm) | 84.1 |
| Inside Diameter (mm) | 38.1 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 1.50 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.9 |
8MJ-8MJ-LX / G93410-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Hex Body (in) | 1.25 |
| Hex Shank (in) | 0.69 |
| Overall Length (in) | 3.88 |
| L Length (in) | 3.88 |
| L Length (mm) | 98.6 |
| Inside Diameter (mm) | 38.1 |
| Max. Working Pressure | 6000 |
| Max. Working Pressure (Bar) | 413.7 |
| Diameter (in) | 1.50 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.9 |
8MJ-8MJ-LX90 / G93415-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.16 |
8MJ-8MJ-LX90S / G93420-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 2.07 |
8MP-8FP-LX90 / G93340-0808
| End 2 Diameter (mm) | 8 |
|---|---|
| Angle. | 90 |
| End 1 Diameter (mm) | 8 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 1.13 |
8ORS/8BSPP LIVE SWVL SEAL KIT / G93700-0008
| Customer Pack | 1 |
|---|---|
| Weight (lbs.) | 0.022 |
Specifications
| End 2 Diameter (mm) | 6 – 32 |
|---|---|
| Hex Body (in) | 0.94 – 3.25 |
| Hex Shank (in) | 0.5 – 2.31 |
| Overall Length (in) | 2.91 – 7.69 |
| L Length (in) | 2.91 – 7.69 |
| L Length (mm) | 73.9 – 195.3 |
| Inside Diameter (mm) | 31.8 – 98.6 |
| Max. Working Pressure | 3000 – 6000 |
| Max. Working Pressure (Bar) | 206.8 – 413.7 |
| Diameter (in) | 1.25 – 3.88 |
| End 1 Diameter (mm) | 6 – 32 |
| Material | Carbon Steel |
| Customer Pack | 1 |
| Weight (lbs.) | 0.02 – 9.91 |
| Angle. | 90 |
PDF Documents
No PDF documents.
