Attributes
| Part Number | 4219-000000-000011 |
|---|
Description
# Standard Fuel and Oil Hose
RECOMMENDED FOR: Fuel line from tank to engine. Also suitable for low pressure hydraulic oil, engine oil, tank vent, crank case vent, or coolant bottle. Not for in-tank, gaseous fuels, or biodiesel above 20% (B20) at 51°C.
- CAUTION: Not recommended for fuel injection systems. Not for in–tank, gaseous fuels, or biol–diesel applications above B5 bio–diesel (80°C /176°F).
- Oil, gasoline and ethanol resistant tube.
- Fuel, oil, ozone and high temperature resistant cover.
- Exceeds requirements of SAE 30R6 and SAE 30R7.
- ARPM (Class A) High oil–resistant tube.
## OE QUALITY FOR THE AFTERMARKET.
Our long-standing partnerships with automotive OEMs on production vehicles enable us to produce aftermarket parts of superior quality, durability, and performance. That experience goes into every Gates® aftermarket engine hose and accessory, bringing a range of solutions for virtually every fluid power component.
## Features and Benefits
- Reinforced with a synthetic fiber reinforcement.
- Nitrile Tube and Modified Nitrile Cover.
- Working pressure: 0,3 to 0,2 MPa.
- Design factor: 6:1.
- Size: 3/16" to 3/4".
- Crimped fittings available.
- Shipped Bulk on Reels (Max. 5 pieces).
- Custom lengths available with minimum order quantity.
## GATES GETS YOUR VEHICLES BACK ON THE ROAD. AND KEEPS THEM THERE.
Gates® develops our automotive aftermarket parts in partnership with the top OEMs around the world, so you can trust premium-grade automotive engine parts that are built to last.
Variations (8)
1/2XRL 4219G FUEL LINE 35
| Dynamic WP (Max.psi) (1) | 35 |
|---|---|
| Vacuum (In. Hg) | 10 |
| Continuous Operating Temperature Range | -40°F to +257°F |
| Minimum Bend Radius (in) | 5 |
| Minimum Bend Radius (mm) | 127 |
| Min. Burst Pressure (psi) | 175 |
| Hose Inside Diameter (in). | 0.78 |
| Hose Inside Diameter (mm) | 19.8 |
| Hose Outside Diameter (in) | 0.78 |
| Hose Outside Diameter (mm) | 19.8 |
| Inside Diameter (in) | 0.5 |
| Inside Diameter (mm) | 12.7 |
| Max. Working Pressure | 35 |
| Max. Working Pressure (Bar) | 2 |
| Working Pressure (psi) | 35 |
| Length (m) | 167.6 |
| Outside Diameter (in) | 0.78 |
| Outside Diameter (mm) | 12.7 |
| Markets/Applications | Fuel |
| Color | Black |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Standards | Exceeds requirements of SAE 30R6 and SAE 30R7. |
| Standard Industry Specification | SAE 30R6, SAE 30R7 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Standards: Tube | ARPM Class A |
| Recommended For | Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. |
| Caution | Not recommended for fuel injection systems. |
| Customer Pack | 550 |
| Weight (lbs.) | 0.268 |
1/4XRL 4219G FUEL LINE 50
| Dynamic WP (Max.psi) (1) | 50 |
|---|---|
| Vacuum (In. Hg) | 24 |
| Continuous Operating Temperature Range | -40°F to +257°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 76 |
| Min. Burst Pressure (psi) | 250 |
| Hose Inside Diameter (in). | 0.5 |
| Hose Inside Diameter (mm) | 12.7 |
| Hose Outside Diameter (in) | 0.5 |
| Hose Outside Diameter (mm) | 12.7 |
| Inside Diameter (in) | 0.25 |
| Inside Diameter (mm) | 6.4 |
| Max. Working Pressure | 50 |
| Max. Working Pressure (Bar) | 3 |
| Working Pressure (psi) | 50 |
| Length (m) | 167.6 |
| Outside Diameter (in) | 0.5 |
| Outside Diameter (mm) | 6.4 |
| Markets/Applications | Fuel |
| Color | Black |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Standards | Exceeds requirements of SAE 30R6 and SAE 30R7. |
| Standard Industry Specification | SAE 30R6, SAE 30R7 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Standards: Tube | ARPM Class A |
| Recommended For | Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. |
| Caution | Not recommended for fuel injection systems. |
| Customer Pack | 550 |
| Weight (lbs.) | 0.137 |
3EH5600
| Vacuum (In. Hg) | 24 |
|---|---|
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 76 |
| Inside Diameter (in) | 0.19 |
| Inside Diameter (mm) | 4.8 |
| Temperature Range | -40°F to +257°F (-40°C to +125°C) |
| Working Pressure (psi) | 50 |
| Length (m) | 167.6 |
| Outside Diameter (in) | 0.41 |
| Outside Diameter (mm) | 4.8 |
| Color | Black |
| Cover | Modified Nitrile - Type C2. Smooth. |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Construction: Design Factor | 4:1 |
| Construction: Reinforcement | Synthetic textile |
| Construction: Tube | Nitrile - Type C. Black. Ethanol, Gasoline, Oil Resistant |
| Standards: Tube | ARPM Class A |
3/4XCTN 4219G FUEL LINE 35
| Vacuum (In. Hg) | 10 |
|---|---|
| Minimum Bend Radius (in) | 7 |
| Minimum Bend Radius (mm) | 178 |
| Inside Diameter (in) | 0.75 |
| Inside Diameter (mm) | 19.1 |
| Temperature Range | -40°F to +257°F (-40°C to +125°C) |
| Working Pressure (psi) | 35 |
| Length (m) | 61 |
| Outside Diameter (in) | 1.13 |
| Outside Diameter (mm) | 19.1 |
| Color | Black |
| Cover | Modified Nitrile - Type C2. Smooth. |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Construction: Design Factor | 4:1 |
| Construction: Reinforcement | Synthetic textile |
| Construction: Tube | Nitrile - Type C. Black. Ethanol, Gasoline, Oil Resistant |
| Standards: Tube | ARPM Class A |
3/8XRL 4219G FUEL LINE 50
| Vacuum (In. Hg) | 24 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +257°F |
| Minimum Bend Radius (in) | 4 |
| Minimum Bend Radius (mm) | 102 |
| Min. Burst Pressure (psi) | 250 |
| Hose Inside Diameter (in). | 0.38 |
| Hose Inside Diameter (mm) | 9.5 |
| Hose Outside Diameter (in) | 0.62 |
| Hose Outside Diameter (mm) | 15.7 |
| Inside Diameter (in) | 0.38 |
| Inside Diameter (mm) | 9.5 |
| Working Pressure (psi) | 50 |
| Length (m) | 167.6 |
| Outside Diameter (in) | 0.62 |
| Outside Diameter (mm) | 9.5 |
| Color | Black |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Standards | Exceeds requirements of SAE 30R6 and SAE 30R7. |
| Standard Industry Specification | SAE 30R6, SAE 30R7 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Standards: Tube | ARPM Class A |
| Recommended For | Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. |
| Caution | Not recommended for fuel injection systems. |
| Customer Pack | 550 |
| Weight (lbs.) | 0.1546 |
5/16XRL 4219G FUEL LINE 50
| Vacuum (In. Hg) | 24 |
|---|---|
| Continuous Operating Temperature Range | -40°F to +257°F |
| Minimum Bend Radius (in) | 3 |
| Minimum Bend Radius (mm) | 76 |
| Min. Burst Pressure (psi) | 250 |
| Hose Inside Diameter (in). | 0.31 |
| Hose Inside Diameter (mm) | 7.9 |
| Hose Outside Diameter (in) | 0.56 |
| Hose Outside Diameter (mm) | 14.2 |
| Inside Diameter (in) | 0.31 |
| Inside Diameter (mm) | 7.9 |
| Working Pressure (psi) | 50 |
| Length (m) | 167.6 |
| Outside Diameter (in) | 0.56 |
| Outside Diameter (mm) | 7.9 |
| Color | Black |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Standards | Exceeds requirements of SAE 30R6 and SAE 30R7. |
| Standard Industry Specification | SAE 30R6, SAE 30R7 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Standards: Tube | ARPM Class A |
| Recommended For | Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. |
| Caution | Not recommended for fuel injection systems. |
| Customer Pack | 550 |
| Weight (lbs.) | 0.115 |
5/32XRL 4219G FUEL LINE 50
| Dynamic WP (Max.psi) (1) | 50 |
|---|---|
| Vacuum (In. Hg) | 24 |
| Continuous Operating Temperature Range | -40°F to +257°F |
| Minimum Bend Radius (in) | 2 |
| Minimum Bend Radius (mm) | 51 |
| Min. Burst Pressure (psi) | 250 |
| Hose Inside Diameter (in). | 0.35 |
| Hose Inside Diameter (mm) | 8.9 |
| Hose Outside Diameter (in) | 0.35 |
| Hose Outside Diameter (mm) | 8.9 |
| Inside Diameter (in) | 0.16 |
| Inside Diameter (mm) | 4 |
| Max. Working Pressure | 50 |
| Max. Working Pressure (Bar) | 3 |
| Working Pressure (psi) | 50 |
| Length (m) | 167.6 |
| Outside Diameter (in) | 0.36 |
| Outside Diameter (mm) | 4 |
| Markets/Applications | Fuel |
| Color | Black |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Standards | Exceeds requirements of SAE 30R6 and SAE 30R7. |
| Standard Industry Specification | SAE 30R6, SAE 30R7 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Standards: Tube | ARPM Class A |
| Recommended For | Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. |
| Caution | Not recommended for fuel injection systems. |
| Customer Pack | 550 |
| Weight (lbs.) | 0.09 |
5/8XRL 4219G FUEL LINE 35
| Dynamic WP (Max.psi) (1) | 35 |
|---|---|
| Vacuum (In. Hg) | 10 |
| Continuous Operating Temperature Range | -40°F to +257°F |
| Minimum Bend Radius (in) | 6 |
| Minimum Bend Radius (mm) | 152 |
| Min. Burst Pressure (psi) | 175 |
| Hose Inside Diameter (in). | 0.94 |
| Hose Inside Diameter (mm) | 23.9 |
| Hose Outside Diameter (in) | 0.94 |
| Hose Outside Diameter (mm) | 23.9 |
| Inside Diameter (in) | 0.63 |
| Inside Diameter (mm) | 15.9 |
| Max. Working Pressure | 35 |
| Max. Working Pressure (Bar) | 2 |
| Working Pressure (psi) | 35 |
| Length (m) | 167.6 |
| Outside Diameter (in) | 0.94 |
| Outside Diameter (mm) | 15.9 |
| Markets/Applications | Fuel |
| Color | Black |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Standards | Exceeds requirements of SAE 30R6 and SAE 30R7. |
| Standard Industry Specification | SAE 30R6, SAE 30R7 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Standards: Tube | ARPM Class A |
| Recommended For | Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. |
| Caution | Not recommended for fuel injection systems. |
| Customer Pack | 550 |
| Weight (lbs.) | 0.352 |
Specifications
| Dynamic WP (Max.psi) (1) | 35 – 50 |
|---|---|
| Vacuum (In. Hg) | 10 – 24 |
| Continuous Operating Temperature Range | -40°F to +257°F |
| Minimum Bend Radius (in) | 2 – 7 |
| Minimum Bend Radius (mm) | 51 – 178 |
| Min. Burst Pressure (psi) | 175 – 250 |
| Hose Inside Diameter (in). | 0.31 – 0.94 |
| Hose Inside Diameter (mm) | 7.9 – 23.9 |
| Hose Outside Diameter (in) | 0.35 – 0.94 |
| Hose Outside Diameter (mm) | 8.9 – 23.9 |
| Inside Diameter (in) | 0.16 – 0.75 |
| Inside Diameter (mm) | 4 – 19.1 |
| Max. Working Pressure | 35 – 50 |
| Max. Working Pressure (Bar) | 2 – 3 |
| Working Pressure (psi) | 35 – 50 |
| Length (m) | 61 – 167.6 |
| Outside Diameter (in) | 0.36 – 1.13 |
| Outside Diameter (mm) | 4 – 19.1 |
| Markets/Applications | Fuel |
| Color | Black |
| Reinforcement | Synthetic textile |
| Tube | Nitrile - Type C. Ethanol, Gasoline, Oil Resistant. |
| Construction: Cover | Modified Nitrile - Type C2 |
| Standards | Exceeds requirements of SAE 30R6 and SAE 30R7. |
| Standard Industry Specification | SAE 30R6, SAE 30R7 |
| Meets These Agency Specifications | SAE - Society of Automotive Engineers |
| Standards: Tube | ARPM Class A |
| Recommended For | Fuel line applications to provide flexible connections between rigid fuel distribution lines and the engine. Also for use in evaporative emission control systems and as a vent line. |
| Caution | Not recommended for fuel injection systems. |
| Customer Pack | 550 |
| Weight (lbs.) | 0.09 – 0.352 |
| Temperature Range | -40°F to +257°F (-40°C to +125°C) |
| Cover | Modified Nitrile - Type C2. Smooth. |
| Construction: Design Factor | 4:1 |
| Construction: Reinforcement | Synthetic textile |
| Construction: Tube | Nitrile - Type C. Black. Ethanol, Gasoline, Oil Resistant |
PDF Documents
No PDF documents.
