Attributes
| Part Number | 9268-000000-000000 |
|---|
Description
# Poly Chain® GT™ Carbon™ EL Belts
Gates Poly Chain GT Carbon belts are renowned for high performance with no maintenance. Now Gates introduces a Poly Chain solution that can handle longer center distances than ever before. The unique manufacturing process allows longer Poly Chain endless belts that deliver high load carrying capabilities. In the past, large and heavy roller chains were the only option for long center distance drives.
Now there is an alternative that requires less maintenance and fewer replacements, resulting in less downtime and cleaner operation. The Extended Length process is applied to belt lengths in 14M pitch over 4410 mm.
- Durable polyurethane construction resists chemicals, oil, pollutants and abrasion.
- Robust carbon tensile cord combines minimal stretch with extraordinary strength and load carrying capacity.
- Nylon tooth facing reduces friction and eliminates the need for lubrication.
- Gates curvilinear tooth profile provides high shear strength and improved load carrying capacity.
- Equivalent capacity to roller chain drives in the same width that offer a maintenance-free, clean solution with no lubrication or retensioning required.
## Features and Benefits
- Robust carbon tensile cord combines minimal stretch with extraordinary strength while absorbing shock and surge loads.
- Endless lengths up to 20,000 mm.
- Equivalent capacity to roller chain drives in the same width.
- Lubrication and maintenance free.
- 96% less weight over chain solution.
- Resists chemicals, oil, pollutants and abrasion.
- Temperature Range: -54°C to +85°C.
- High power density.
- Perfect fit on Poly Chain® GT™ profile pulleys.
- Available in 14mm and 19mm pitch.
Variations (236)
14MGT-10234EL-68
No variation attributes.
14MGT-1120
No variation attributes.
14MGT-1120-34
No variation attributes.
14MGT-1120-56
No variation attributes.
14MGT-1190
No variation attributes.
14MGT-1260
No variation attributes.
14MGT-1400
No variation attributes.
14MGT-1400-55
No variation attributes.
14MGT-1568
No variation attributes.
14MGT-1568-18
No variation attributes.
14MGT-1568-50
No variation attributes.
14MGT-1568-55
No variation attributes.
14MGT-1568-62
No variation attributes.
14MGT-1568-75
No variation attributes.
14MGT-1610
No variation attributes.
14MGT-1610-37MS5
No variation attributes.
14MGT-1750
No variation attributes.
14MGT-1750-37MS6
No variation attributes.
14MGT-18004EL-125
No variation attributes.
14MGT-1890
No variation attributes.
14MGT-1890-150
No variation attributes.
14MGT-19320EL-68
No variation attributes.
14MGT-1960
No variation attributes.
14MGT-1960-100
No variation attributes.
14MGT-1960-170
No variation attributes.
14MGT-1960-45
No variation attributes.
14MGT-2100
No variation attributes.
14MGT-2100-150
No variation attributes.
14MGT-2100-55
No variation attributes.
14MGT-2240
No variation attributes.
14MGT-2240-25
No variation attributes.
14MGT-2310
No variation attributes.
14MGT-2310-120
No variation attributes.
14MGT-2380
No variation attributes.
14MGT-2380-150
No variation attributes.
14MGT-2380-25.4
No variation attributes.
14MGT-2380-28
No variation attributes.
14MGT-2380-54
No variation attributes.
14MGT-2450
No variation attributes.
14MGT-2520
No variation attributes.
14MGT-2590
No variation attributes.
14MGT-2660
No variation attributes.
14MGT-2730
No variation attributes.
14MGT-2800
No variation attributes.
14MGT-2800-115
No variation attributes.
14MGT-2800-65
No variation attributes.
14MGT-3136
No variation attributes.
14MGT-3136-170
No variation attributes.
14MGT-3136-170MS2
No variation attributes.
14MGT-3136-250
No variation attributes.
14MGT-3304
No variation attributes.
14MGT-3304-200
No variation attributes.
14MGT-3304-60
No variation attributes.
14MGT-3360
No variation attributes.
14MGT-3500
No variation attributes.
14MGT-3850
No variation attributes.
14MGT-3850-100MS3
No variation attributes.
14MGT-3920
No variation attributes.
14MGT-3920-100MS3
No variation attributes.
14MGT-3920-112.5MS2
No variation attributes.
14MGT-3920-115
No variation attributes.
14MGT-3920-255
No variation attributes.
14MGT-3920-90MS2
No variation attributes.
14MGT-4326-135
No variation attributes.
14MGT-4326-85
No variation attributes.
14MGT-4410
No variation attributes.
14MGT-4410-110MS2
No variation attributes.
14MGT-4410-112.5MS2
No variation attributes.
14MGT-4410-115MS2
No variation attributes.
14MGT-4410-150
No variation attributes.
14MGT-4410-180
No variation attributes.
14MGT-4410-190
No variation attributes.
14MGT-4410-225
No variation attributes.
14MGT-4410-225MS2
No variation attributes.
14MGT-4410-290
No variation attributes.
14MGT-4410-340
No variation attributes.
14MGT-4410-90MS2
No variation attributes.
14MGT-4578EL-115
No variation attributes.
14MGT-4578EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 180.24 |
| Pitch Length (mm) | 4578 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 327 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 4.438 |
14MGT-4578EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 180.24 |
| Pitch Length (mm) | 4578 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 327 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.17 |
14MGT-4578EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 180.24 |
| Pitch Length (mm) | 4578 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 327 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.412 |
14MGT-4578EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 180.24 |
| Pitch Length (mm) | 4578 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 327 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 3.195 |
14MGT-4578EL-90 AY2
No variation attributes.
14MGT-4788EL-170
No variation attributes.
14MGT-4956EL-100
No variation attributes.
14MGT-4956EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 195.12 |
| Pitch Length (mm) | 4956 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 354 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 5.23 |
14MGT-4956EL-155
No variation attributes.
14MGT-4956EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 195.12 |
| Pitch Length (mm) | 4956 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 354 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 1.422 |
14MGT-4956EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 195.12 |
| Pitch Length (mm) | 4956 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 354 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.615 |
14MGT-4956EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 195.12 |
| Pitch Length (mm) | 4956 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 354 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 3.461 |
14MGT-5138EL-37 UN30
No variation attributes.
14MGT-5320EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 209.45 |
| Pitch Length (mm) | 5320 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 380 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 5.198 |
14MGT-5320EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 209.45 |
| Pitch Length (mm) | 5320 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 380 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 1.526 |
14MGT-5320EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 209.45 |
| Pitch Length (mm) | 5320 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 380 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.804 |
14MGT-5320EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 209.45 |
| Pitch Length (mm) | 5320 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 380 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 4.68 |
14MGT-5600EL-115
No variation attributes.
14MGT-5740EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 225.98 |
| Pitch Length (mm) | 5740 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 410 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 5.606 |
14MGT-5740EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 225.98 |
| Pitch Length (mm) | 5740 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 410 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 1.647 |
14MGT-5740EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 225.98 |
| Pitch Length (mm) | 5740 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 410 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 3.029 |
14MGT-5740EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 225.98 |
| Pitch Length (mm) | 5740 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 410 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 4.005 |
14MGT-5768EL-68
No variation attributes.
14MGT-6160EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 242.52 |
| Pitch Length (mm) | 6160 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 440 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 6.019 |
14MGT-6160EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 242.52 |
| Pitch Length (mm) | 6160 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 440 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 1.769 |
14MGT-6160EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 242.52 |
| Pitch Length (mm) | 6160 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 440 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 3.249 |
14MGT-6160EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 242.52 |
| Pitch Length (mm) | 6160 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 440 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 4.298 |
14MGT-6720EL-37
No variation attributes.
14MGT-6860EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 270.08 |
| Pitch Length (mm) | 6860 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 490 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 6.704 |
14MGT-6860EL-155
No variation attributes.
14MGT-6860EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 270.08 |
| Pitch Length (mm) | 6860 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 490 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 1.967 |
14MGT-6860EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 270.08 |
| Pitch Length (mm) | 6860 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 490 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 3.618 |
14MGT-6860EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 270.08 |
| Pitch Length (mm) | 6860 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 490 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 4.788 |
14MGT-7112EL-90
No variation attributes.
14MGT-7560EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 297.64 |
| Pitch Length (mm) | 7560 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 540 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 7.39 |
14MGT-7560EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 297.64 |
| Pitch Length (mm) | 7560 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 540 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.19 |
14MGT-7560EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 297.64 |
| Pitch Length (mm) | 7560 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 540 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 4.02 |
14MGT-7560EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 297.64 |
| Pitch Length (mm) | 7560 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 540 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 5.33 |
14MGT-7798EL-37
No variation attributes.
14MGT-8260EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 325.2 |
| Pitch Length (mm) | 8260 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 590 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 8.07 |
14MGT-8260EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 325.2 |
| Pitch Length (mm) | 8260 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 590 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.4 |
14MGT-8260EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 325.2 |
| Pitch Length (mm) | 8260 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 590 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 4.4 |
14MGT-8260EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 325.2 |
| Pitch Length (mm) | 8260 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 590 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 5.82 |
14MGT-8694EL-90
No variation attributes.
14MGT-8946EL-90
No variation attributes.
14MGT-8960EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 352.76 |
| Pitch Length (mm) | 8960 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 640 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 8.76 |
14MGT-8960EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 352.76 |
| Pitch Length (mm) | 8960 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 640 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.6 |
14MGT-8960EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 352.76 |
| Pitch Length (mm) | 8960 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 640 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 4.77 |
14MGT-8960EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 352.76 |
| Pitch Length (mm) | 8960 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 640 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 6.31 |
14MGT-9660EL-125
| Belt Width (in) | 4.92 |
|---|---|
| Belt Width (mm) | 125 |
| Pitch Length (in) | 380.31 |
| Pitch Length (mm) | 9660 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 690 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 4.92 |
| Width (mm) | 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 9.44 |
14MGT-9660EL-37
| Belt Width (in) | 1.46 |
|---|---|
| Belt Width (mm) | 37 |
| Pitch Length (in) | 380.31 |
| Pitch Length (mm) | 9660 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 690 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 |
| Width (mm) | 37 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 2.8 |
14MGT-9660EL-40
No variation attributes.
14MGT-9660EL-68
| Belt Width (in) | 2.68 |
|---|---|
| Belt Width (mm) | 68 |
| Pitch Length (in) | 380.31 |
| Pitch Length (mm) | 9660 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M |
| Number of Teeth | 690 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 2.68 |
| Width (mm) | 68 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 5.14 |
14MGT-9660EL-90
| Belt Width (in) | 3.54 |
|---|---|
| Belt Width (mm) | 90 |
| Pitch Length (in) | 380.31 |
| Pitch Length (mm) | 9660 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14MGT |
| Number of Teeth | 690 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 3.54 |
| Width (mm) | 90 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 6.8 |
14MGT-994
No variation attributes.
14MGT-994-50
No variation attributes.
14MGT4326
No variation attributes.
19MGT-4408-250/2
No variation attributes.
19MGT-4408-300/2
No variation attributes.
19MGT-4522-250/2
No variation attributes.
19MGT-4522-300/2
No variation attributes.
14MGT-2240-160
No variation attributes.
14MGT-3136-100
No variation attributes.
14MGT-3500-25
No variation attributes.
14MGT-3920-25
No variation attributes.
92683067
No variation attributes.
92680029
No variation attributes.
92683068
No variation attributes.
92780162
No variation attributes.
92683063
No variation attributes.
92683074
No variation attributes.
93721450
No variation attributes.
92780147
No variation attributes.
92780148
No variation attributes.
92760787
No variation attributes.
93721825
No variation attributes.
92683077
No variation attributes.
92780340
No variation attributes.
92780132
No variation attributes.
92780237
No variation attributes.
93721750
No variation attributes.
92680038
No variation attributes.
92680010
No variation attributes.
92680058
No variation attributes.
93721800
No variation attributes.
93721525
No variation attributes.
92683062
No variation attributes.
92680014
No variation attributes.
92683076
No variation attributes.
92780149
No variation attributes.
92780266
No variation attributes.
93721050
No variation attributes.
92780220
No variation attributes.
92780299
No variation attributes.
92760651
No variation attributes.
92780188
No variation attributes.
92683073
No variation attributes.
93721250
No variation attributes.
92683065
No variation attributes.
92680033
No variation attributes.
92780199
No variation attributes.
92780208
No variation attributes.
92780120
No variation attributes.
92680039
No variation attributes.
92683071
No variation attributes.
93721875
No variation attributes.
92780244
No variation attributes.
93721575
No variation attributes.
93721100
No variation attributes.
92780222
No variation attributes.
93721350
No variation attributes.
92780296
No variation attributes.
93721150
No variation attributes.
92683069
No variation attributes.
93721200
No variation attributes.
92780335
No variation attributes.
93721375
No variation attributes.
92780131
No variation attributes.
92780161
No variation attributes.
93721500
No variation attributes.
92780200
No variation attributes.
92780204
No variation attributes.
92683075
No variation attributes.
93721625
No variation attributes.
92683064
No variation attributes.
92680042
No variation attributes.
93721725
No variation attributes.
92780137
No variation attributes.
92780344
No variation attributes.
93721700
No variation attributes.
92683060
No variation attributes.
92780164
No variation attributes.
92680041
No variation attributes.
92780136
No variation attributes.
93721325
No variation attributes.
93721550
No variation attributes.
92780160
No variation attributes.
92780163
No variation attributes.
92780243
No variation attributes.
93721400
No variation attributes.
93721925
No variation attributes.
92680027
No variation attributes.
92680037
No variation attributes.
92683061
No variation attributes.
92683066
No variation attributes.
92683070
No variation attributes.
92683072
No variation attributes.
92780119
No variation attributes.
92780134
No variation attributes.
92780297
No variation attributes.
93721300
No variation attributes.
93721600
No variation attributes.
93721650
No variation attributes.
93721850
No variation attributes.
93721900
No variation attributes.
93721950
No variation attributes.
92780239
No variation attributes.
92780300
No variation attributes.
Specifications
| Belt Width (in) | 1.46 – 4.92 |
|---|---|
| Belt Width (mm) | 37 – 125 |
| Pitch Length (in) | 180.24 – 380.31 |
| Pitch Length (mm) | 4578 – 9660 |
| Pitch (in) | 0.55 |
| Pitch (mm) | 14 |
| Section | 14M, 14MGT |
| Number of Teeth | 327 – 690 |
| Height (in) | 0.4 |
| Height (mm) | 10.2 |
| Thickness (in) | 0.394 |
| Thickness (mm) | 10.2 |
| Width (in) | 1.46 – 4.92 |
| Width (mm) | 37 – 125 |
| Markets/Applications | All industrial markets requiring long center distance and high load carrying capacity. Especially targeted towards HVAC, roller chain and gear replacement, oil, mining, water treatment plants, pulp and paper, and general manufacturing. |
| Color | Black |
| Material | Polyurethane and Nylon |
| Recommended For | Poly Chain® GT®2 Sprockets - 14M |
| WARNING | Always utilize Taper-Lock® type Poly Chain® GT®2 Sprockets when designing a new Poly Chain® GT® Carbon™ Extended Length™ belt drive system. Use of non-Gates manufactured sprockets is not recommended and product performance cannot be guaranteed when non-Gates sprockets are used. |
| Belt Notes | Poly Chain® GT® Carbon™ Extended Length™ belt part numbers are comprised of pitch, pitch length, extended length indication, and width: part number 14MGT-6890EL-90 denotes a 14mm pitch, 6860mm pitch length in extended length construction, and 90mm width. Poly Chain® GT® Carbon™ Extended Length™ Belts are Standard/Non-Stock and may require lead time. Please check with Customer Service for availability. |
| Customer Pack | 1 |
| Weight (lbs.) | 1.422 – 9.44 |
PDF Documents
No PDF documents.
