Attributes
| Part Number | 4217-110000-000005 |
|---|
Description
# Data Master™ MegaFlex™ Cooling Hose
In high-demand environments, our Data Master MegaFlex cooling hose rises to the challenge. Whether it’s running more liquid through high-volumetric systems, maintaining cleaner coolant over time, preventing kinks, or resisting flame and ozone degradation, our hose is built to keep your systems running smoothly.
Product Samples Available Upon Request
- Proprietary Tube Materials include zinc-free, peroxide-cured EPDM to support your facility water and technology cooling system (TCS) loops with high-flow, flexible hose options.
- Gates MegaFlex design technology provides up to 1.5:1 MBR to hose ID ratio (across size range), allowing tighter bends and easier routing for ever-changing configurations in growing data centers.
- Flame-Resistant Cover: UL94V-0 certified and tested to UL224VW-1 standards for increased safety in high-risk environments.
- FOR USE WITH: CDU to rack manifolds, CDU internal circulation, redundant loop plumbing, and portable chillers and pump carts.
Explore More Data Master Cooling Hose Solutions
.cta-wrapper { margin: 0.8em 0 0.6em 0; text-align: left; } .cta-link { display: inline-block; background-color: #c8102e; /\* Gates red \*/ color: #fff; padding: 0.55em 1.2em; border-radius: 4px; text-decoration: none; font-weight: 600; font-size: 0.95rem; transition: background-color 0.2s ease; } .cta-link:hover { background-color: #a00d24; /\* darker on hover \*/ }
Variations (15)
20DM1090
| Hose Inside Diameter (in). | 1.25 |
|---|---|
| Hose Inside Diameter (mm) | 31.8 |
| Hose Outside Diameter (in) | 1.65 |
| Hose Outside Diameter (mm) | 41.9 |
20DM1091
| Hose Inside Diameter (in). | 1.25 |
|---|---|
| Hose Inside Diameter (mm) | 31.8 |
| Hose Outside Diameter (in) | 1.65 |
| Hose Outside Diameter (mm) | 41.9 |
20DM1092
| Hose Inside Diameter (in). | 1.25 |
|---|---|
| Hose Inside Diameter (mm) | 31.8 |
| Hose Outside Diameter (in) | 1.65 |
| Hose Outside Diameter (mm) | 41.9 |
24DM1090
| Hose Inside Diameter (in). | 1.5 |
|---|---|
| Hose Inside Diameter (mm) | 38.1 |
| Hose Outside Diameter (in) | 1.95 |
| Hose Outside Diameter (mm) | 49.5 |
24DM1091
| Hose Inside Diameter (in). | 1.5 |
|---|---|
| Hose Inside Diameter (mm) | 38.1 |
| Hose Outside Diameter (in) | 1.95 |
| Hose Outside Diameter (mm) | 49.5 |
24DM1092
| Hose Inside Diameter (in). | 1.5 |
|---|---|
| Hose Inside Diameter (mm) | 38.1 |
| Hose Outside Diameter (in) | 1.95 |
| Hose Outside Diameter (mm) | 49.5 |
32DM1090
| Hose Inside Diameter (in). | 2 |
|---|---|
| Hose Inside Diameter (mm) | 50.8 |
| Hose Outside Diameter (in) | 2.4 |
| Hose Outside Diameter (mm) | 61.2 |
32DM1091
| Hose Inside Diameter (in). | 2 |
|---|---|
| Hose Inside Diameter (mm) | 50.8 |
| Hose Outside Diameter (in) | 2.4 |
| Hose Outside Diameter (mm) | 61.2 |
32DM1092
| Hose Inside Diameter (in). | 2 |
|---|---|
| Hose Inside Diameter (mm) | 50.8 |
| Hose Outside Diameter (in) | 2.4 |
| Hose Outside Diameter (mm) | 61.2 |
48DM1090
| Minimum Bend Radius (in) | 3 |
|---|---|
| Minimum Bend Radius (mm) | 76.2 |
| Min. Burst Pressure (psi) | 600 |
| Hose Inside Diameter (in). | 3 |
| Hose Inside Diameter (mm) | 76.2 |
| Hose Outside Diameter (in) | 3.5 |
| Hose Outside Diameter (mm) | 87.6 |
48DM1091
| Minimum Bend Radius (in) | 3 |
|---|---|
| Minimum Bend Radius (mm) | 76.2 |
| Min. Burst Pressure (psi) | 600 |
| Hose Inside Diameter (in). | 3 |
| Hose Inside Diameter (mm) | 76.2 |
| Hose Outside Diameter (in) | 3.5 |
| Hose Outside Diameter (mm) | 87.6 |
48DM1092
| Minimum Bend Radius (in) | 3 |
|---|---|
| Minimum Bend Radius (mm) | 76.2 |
| Min. Burst Pressure (psi) | 600 |
| Hose Inside Diameter (in). | 3 |
| Hose Inside Diameter (mm) | 76.2 |
| Hose Outside Diameter (in) | 3.5 |
| Hose Outside Diameter (mm) | 87.6 |
64DM1090
| Minimum Bend Radius (in) | 4 |
|---|---|
| Minimum Bend Radius (mm) | 101.6 |
| Min. Burst Pressure (psi) | 600 |
| Hose Inside Diameter (in). | 4 |
| Hose Inside Diameter (mm) | 101.6 |
| Hose Outside Diameter (in) | 4.5 |
| Hose Outside Diameter (mm) | 113 |
64DM1091
| Minimum Bend Radius (in) | 4 |
|---|---|
| Minimum Bend Radius (mm) | 101.6 |
| Min. Burst Pressure (psi) | 600 |
| Hose Inside Diameter (in). | 4 |
| Hose Inside Diameter (mm) | 101.6 |
| Hose Outside Diameter (in) | 4.5 |
| Hose Outside Diameter (mm) | 113 |
64DM1092
| Minimum Bend Radius (in) | 4 |
|---|---|
| Minimum Bend Radius (mm) | 101.6 |
| Min. Burst Pressure (psi) | 600 |
| Hose Inside Diameter (in). | 4 |
| Hose Inside Diameter (mm) | 101.6 |
| Hose Outside Diameter (in) | 4.5 |
| Hose Outside Diameter (mm) | 113 |
Specifications
| Hose Inside Diameter (in). | 1.25 – 4 |
|---|---|
| Hose Inside Diameter (mm) | 31.8 – 101.6 |
| Hose Outside Diameter (in) | 1.65 – 4.5 |
| Hose Outside Diameter (mm) | 41.9 – 113 |
| Minimum Bend Radius (in) | 3 – 4 |
| Minimum Bend Radius (mm) | 76.2 – 101.6 |
| Min. Burst Pressure (psi) | 600 |
